Before Use
Names of the Components
1Flash (P62)
2 Self-timer indicator (P69)/
AF Assist Lamp (P121)/LED light (P123)
3 Lens (P177, 178)
4 LCD monitor (P60, 172)
5 Motion picture button (P42)
6 [MENU/SET] button (P29)
7 [DISPLAY] button (P60)
8 [Q.MENU] (P34)/Delete button (P58)
9 Playback button (P31, 42)
10 Mode dial (P42)
11 Cursor buttons
A: 3/Exposure Compensation (P70)/
Auto Bracket (P71)/White Balance
fine adjustment (P111)
B: 4/Macro Mode (P67)/
AF Tracking (P47, 114)
C: 2/Self-timer button (P69)
D: 1/Flash setting button (P62)
In these Operating Instructions, the cursor buttons are described as shown in the
figure below or described with 3/4/2/1.
e.g.: When you press the 4 (down) button
or Press 4
21 3
4511
786
9
10
