Panasonic Lumix DMC-TS25 User Manual

- 153 -
Others
• Press [MENU/SET] after viewing the last screen (12/12). For details, refer to P9.
> Press [MENU/SET], select the [Setup] menu icon [ ]. Then press [MENU/SET], and then
select the [~] icon to set the desired language. (P50)
• AF Assist Lamp will turn on white in the dark place to assist the focusing.
• Is [AF Assist Lamp] on the [Rec] menu set to [ON]? (P95)
• The AF Assist Lamp does not turn on in bright places.
• The surface of the camera may become warm during use. This does not affect the performance or
quality of the camera.
• When the brightness changes due to zoom or camera movement, etc., the lens may click and the
picture on the screen may drastically change. However, the picture is not affected. The sound is
caused by the automatic adjustment of the aperture. This is not a malfunction.
• Have foreign objects become trapped?
> Remove the foreign objects. (P10)
• When closing, do not set the [LOCK] switch to the locked side. Doing so may cause damage or
leaks.
> Release the lock. (P20)
• If the camera is used in cold places such as ski resorts or places at high altitude with the snow or
water droplets adhered to the camera, some parts of the camera may become hard to move with
snow or water droplets freezing in the gap of the zoom button or the camera [ON/OFF] button. This
is not a malfunction. When the camera returns to normal temperature it will function as normal.
• When using the camera in a place with sand or dust, some parts of the camera may become hard to
move with foreign objects getting in the gap of the zoom button, or the camera [ON/OFF] button.
Wipe off with a dry, lint-free cloth or rinse with fresh water.
Others
[Requirements for Underwater use] is displayed repeatedly whenever this unit is
turned on.
An unreadable language was selected by mistake.
A white lamp sometimes turns on when the shutter button is pressed halfway.
The AF Assist Lamp does not turn on.
The camera becomes warm.
The lens clicks.
The side door will not close.
A part of the camera such as the zoom button and side door does not move.

Panasonic Lumix DMC-TS25 Specifications

General

Megapixel	16.1 MP
Camera type	Compact camera
Sensor type	CCD
Image stabilizer	Yes
Total megapixels	16.6 MP
Image sensor size	1/2.33 \
Image formats supported	JPG
Supported aspect ratios	3:2, 4:3, 16:9
Maximum image resolution	4608 x 3456 pixels
Still image resolution(s)	640 x 480, 1280 x 960, 2048 x 1536, 2560 x 1920, 3456 x 3456, 3648 x 2736, 4608 x 2592, 4608 x 3072, 4608 x 3456
Optical zoom	4 x
Focal length range	4.5 - 18 mm
Maximum aperture number	5.7
Minimum aperture number	3.9
Lens structure (elements/groups)	11/7
Maximum focal length (35mm film equiv)	100 mm
Minimum focal length (35mm film equiv)	25 mm
Focus adjustment	Auto
Normal focusing range	0.5 - ∞ m
Auto focusing (AF) modes	Continuous Auto Focus, Tracking Auto Focus
Macro focusing range (tele)	1 - ∞ m
Macro focusing range (wide)	0.05 - ∞ m
ISO sensitivity	100, 200, 400, 800, 1600, 6400
ISO sensitivity (max)	6400
ISO sensitivity (min)	100
Light exposure control	Program AE
Light exposure correction	± 2EV (1/3EV step)
Fastest camera shutter speed	1/1300 s
Slowest camera shutter speed	60 s
Flash modes	Auto, Forced off, Forced on, Red-eye reduction, Slow synchronization
Flash range (tele)	1 - 3 m
Flash range (wide)	0.3 - 4.4 m
Power source type	Battery
Video resolutions	640 x 480, 1280 x 720 pixels
Motion JPEG frame rate	30 fps
Video formats supported	AVCHD, MP4
Maximum video resolution	1280 x 720 pixels
Internal memory	70 MB
Compatible memory cards	SD, SDHC, SDXC
Display diagonal	2.7 \
Display resolution (numeric)	230000 pixels
Product color	Silver
Scene modes	Beach, Children, Night portrait, Panorama, Portrait, Snow, Sports, Underwater
Image editing	Crop, Resizing
Photo effects	Black&White, Sepia, Vivid
White balance	Auto, Cloudy, Daylight, Incandescent, Shade
Camera playback	Slide show, Thumbnails
Self-timer delay	2, 10 s
Camera file system	DCF, DPOF 1.1, Exif 2.3
On Screen Display (OSD) languages	ENG, ESP
Battery life (CIPA standard)	250 shots
Number of batteries supported	1
Bundled software	PHOTOfunSTUDIO 9.0 SE / Adobe Reader

Weight and Dimensions

Depth	19.7 mm
Width	103.7 mm
Height	58.3 mm
Weight	125 g
Weight (including battery)	144 g
