- 154 -
Others
Below cases are not malfunctions, so you can use the camera as normal.
> You hear a “rattling” sound when the camera is shaken while this unit is turned off or during
Playback Mode (this is the sound of the lens moving).
> When this unit is turned on or off, or when switching from recording to Playback Mode, there is a
rattling noise (this is the sound of the lens moving).
> When zooming, you can feel some vibration (this is caused by the lens moving).
If you do not use the camera for a long time, the clock may be reset.
> [Please set the clock] message will be displayed, please reset the clock. (P25)
It is possible that the subject may be warped slightly, or the borders get colored, depending on the
zoom magnification, due to the characteristics of the lens, but this is not a malfunction.
When using the Extended Optical zoom, the zooming action will stop temporarily. This is not a
malfunction.
Is the camera set to Macro Zoom Mode? (P58)
Maximum zoom during Macro Zoom Mode is 3k digital zoom.
When you perform an operation after taking a certain action, the pictures may be recorded in folders
with different numbers from the ones used prior to the operation.
If you insert or remove the battery before turning off this unit, the folder and file numbers for the
pictures taken will not be stored in the memory. When this unit is turned on again and pictures are
taken, they may be stored under file numbers which should have been assigned to previous
pictures.
Formatting is not available in Intelligent Auto Mode. Switch the recording mode to another one. (P50)
The camera makes a rattling sound or you can feel some vibration.
The clock is reset.
When pictures are taken using the zoom, they are slightly distorted and the areas
around the subject contain colors which are not actually present.
Zooming stops instantaneously.
Zoom does not go up to maximum magnification.
The file numbers are not recorded consecutively.
The file numbers are recorded with previously used numbers.
The card cannot be formatted.

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Panasonic Lumix DMC-TS25 and is the answer not in the manual?

Panasonic Lumix DMC-TS25 Specifications

General IconGeneral
Megapixel16.1 MP
Camera typeCompact camera
Sensor typeCCD
Image stabilizerYes
Total megapixels16.6 MP
Image sensor size1/2.33 \
Image formats supportedJPG
Supported aspect ratios3:2, 4:3, 16:9
Maximum image resolution4608 x 3456 pixels
Still image resolution(s)640 x 480, 1280 x 960, 2048 x 1536, 2560 x 1920, 3456 x 3456, 3648 x 2736, 4608 x 2592, 4608 x 3072, 4608 x 3456
Optical zoom4 x
Focal length range4.5 - 18 mm
Maximum aperture number5.7
Minimum aperture number3.9
Lens structure (elements/groups)11/7
Maximum focal length (35mm film equiv)100 mm
Minimum focal length (35mm film equiv)25 mm
Focus adjustmentAuto
Normal focusing range0.5 - ∞ m
Auto focusing (AF) modesContinuous Auto Focus, Tracking Auto Focus
Macro focusing range (tele)1 - ∞ m
Macro focusing range (wide)0.05 - ∞ m
ISO sensitivity100, 200, 400, 800, 1600, 6400
ISO sensitivity (max)6400
ISO sensitivity (min)100
Light exposure controlProgram AE
Light exposure correction± 2EV (1/3EV step)
Fastest camera shutter speed1/1300 s
Slowest camera shutter speed60 s
Flash modesAuto, Forced off, Forced on, Red-eye reduction, Slow synchronization
Flash range (tele)1 - 3 m
Flash range (wide)0.3 - 4.4 m
Power source typeBattery
Video resolutions640 x 480, 1280 x 720 pixels
Motion JPEG frame rate30 fps
Video formats supportedAVCHD, MP4
Maximum video resolution1280 x 720 pixels
Internal memory70 MB
Compatible memory cardsSD, SDHC, SDXC
Display diagonal2.7 \
Display resolution (numeric)230000 pixels
Product colorSilver
Scene modesBeach, Children, Night portrait, Panorama, Portrait, Snow, Sports, Underwater
Image editingCrop, Resizing
Photo effectsBlack&White, Sepia, Vivid
White balanceAuto, Cloudy, Daylight, Incandescent, Shade
Camera playbackSlide show, Thumbnails
Self-timer delay2, 10 s
Camera file systemDCF, DPOF 1.1, Exif 2.3
On Screen Display (OSD) languagesENG, ESP
Battery life (CIPA standard)250 shots
Number of batteries supported1
Bundled softwarePHOTOfunSTUDIO 9.0 SE / Adobe Reader
Weight and Dimensions IconWeight and Dimensions
Depth19.7 mm
Width103.7 mm
Height58.3 mm
Weight125 g
Weight (including battery)144 g
