Panasonic Lumix DMC-TS3

VQT3L22 (ENG)
16
Names of the Components
1Flash
2 Self-timer indicator/
AF Assist Lamp/LED light
3Lens
4 LCD monitor
5 Speaker
6 Zoom button
7 Playback button
8 [MODE] button
9 [MENU/SET] button
10 [Q.MENU]/Delete/Cancel button
11 [DISP.] button
12 Cursor buttons
A: 3/Exposure compensation
Auto Bracket
B: 4/Macro Mode
AF Tracking
C: 2/Self-timer
D: 1/Flash setting
In this Owner’s Manual, the cursor buttons are described as shown in
the figure below or described with 3/4/2/1.
e.g.: When you press the 4 (down) button
or Press 4
21 3
456
11
10
12
8
9
7
MENU
/SET
MENU
/SET
