Panasonic Lumix DMC-TS3

Before Use
- 15 -
13 Motion picture button (P36)
14 Shutter button (P30, 39)
15 Camera [OFF/ON] button (P27)
16 GPS antenna (P83)
17 Microphone
18 GPS status indicator
19 Tripod receptacle
20 [HDMI] socket (P140, 142)
21 [AV OUT/DIGITAL] socket (P139, 147, 150, 153)
22 Strap eyelet (P16)
•
Be sure to attach the strap when using the camera
to ensure that you will not drop it.
23 Release lever (P21)
24 [LOCK] switch (P10, 21)
25 Side door (P10, 21)
•
When using an AC adaptor, ensure that
the Panasonic DC coupler (optional) and
AC adaptor (optional) are used. For
connection details, refer to P23.
13
14
15
16
18
17
19
