Panasonic Lumix DMC-TZ30 Operating Instructions

- 112 -
Different playback methods [Playback Mode]
[Slide Show]
• For switching [Playback Mode] (→111)
Automatically play pictures in order and to music. Recommended when viewing on TV
screen.
Use cursor button to select the playback method and press
[MENU/SET]
[All] Play all.
[Picture Only] Plays back still pictures.
[Motion Pic. Only] Plays back motion pictures.
[3D Play] Plays back only 3D still pictures that were recorded in [3D Photo
Mode].
[GPS Area Play] Selects place name or landmark to play back pictures recorded in the
same place. (Use cursor button to select place name or landmark and
press [MENU/SET].)
[Travel] Play only pictures that were recorded with the [Travel Setup] or
[Location]. (→114)
[Category
Selection]
Select category and play back motion or still pictures.
(Select category with cursor button and press [MENU/SET].) (→114)
[Favorite] Play back pictures set as [Favorite]. (→123)
Use cursor button to set playback effects and press [MENU/
SET]
[Effect] (Select music and effects according to picture atmosphere)
[AUTO] (only available with [Category Selection] setting) / [NATURAL] / [SLOW] / [SWING] /
[URBAN] / [OFF]
∗
[Setup]
[Duration]
∗
[1SEC] / [2SEC] / [3SEC] / [5SEC] (Only available when [Effect] is [OFF])
[Repeat] [ON] / [OFF]
[Sound]
[OFF]: Music and audio will not play back.
[AUTO]: With still pictures, music will play back, and with motion pictures,
audio will play back.
[Music]: Music effect will play back.
[Audio]: Audio is played back from motion pictures.
∗
In the following case, [Effect] is fixed to [OFF]. The [Duration] setting is also disabled.
• [Motion Pic. Only]
• [Burst] of [Category Selection]
Select [Start] with cursor button and press [MENU/SET]

Panasonic Lumix DMC-TZ30 Specifications

General

Megapixel	14.1 MP
Camera type	Compact camera
Sensor type	Live MOS
Image stabilizer	Yes
Total megapixels	15.3 MP
Image sensor size	1/2.33 \
Supported aspect ratios	3:2, 4:3, 16:9
Maximum image resolution	4320 x 3240 pixels
Still image resolution(s)	480 x 480, 640 x 360, 640 x 424, 640 x 480, 1536 x 1536, 1920 x 1080, 1920 x 1920, 2048 x 1360, 2048 x 1536, 2304 x 2304, 2560 x 1440, 2560 x 1712, 2560 x 1920, 2736 x 2736, 3072 x 1728, 3072 x 2048, 3072 x 2304, 3232 x 3232, 3648 x 2056, 3648 x 2432, 3648 x 2736, 4320 x 2432, 4320 x 2880, 4320 x 3240
Digital zoom	4 x
Optical zoom	20 x
Extra/Smart zoom	42.2 x
Focal length range	4.3 - 86 mm
Maximum aperture number	6.4
Minimum aperture number	3.3
Number of aspheric elements	3
Lens structure (elements/groups)	12/10
Maximum focal length (35mm film equiv)	480 mm
Minimum focal length (35mm film equiv)	24 mm
Focus	TTL
Focus adjustment	Auto
Normal focusing range	0.5 - ∞/2 - ∞ m
Auto focusing (AF) modes	Continuous Auto Focus, Tracking Auto Focus
Macro focusing range (tele)	1 - ∞ m
Macro focusing range (wide)	0.03 - ∞ m
Normal focusing range (tele)	2 - ∞ m
Normal focusing range (wide)	0.5 - ∞ m
Light metering	Centre-weighted, Evaluative (Multi-pattern), Spot
ISO sensitivity	100, 200, 400, 800, 1600, 3200, 6400, Auto
Light exposure modes	Aperture priority AE, Manual, Shutter priority AE
ISO sensitivity (max)	6400
ISO sensitivity (min)	100
Light exposure control	Program AE
Light exposure correction	± 2EV (1/3EV step)
Fastest camera shutter speed	1/2000 s
Slowest camera shutter speed	15 s
Flash modes	Auto, Forced off, Forced on, Red-eye reduction, Slow synchronization
Flash range (tele)	1 - 3.3 m
Flash range (wide)	0.6 - 6.4 m
Digital SLR	No
Power source type	Battery
Video resolutions	320 x 240, 640 x 480, 1280 x 720, 1920 x 1080 pixels
Video formats supported	AVCHD, M-JPEG, MOV, MP4
Maximum video resolution	1920 x 1080 pixels
Analog signal format system	NTSC, PAL
Audio system	Mono
Internal memory	12 MB
Compatible memory cards	SD, SDHC, SDXC
Field of view	100 %
Display diagonal	3 \
Display resolution (numeric)	460000 pixels
USB version	2.0
Product color	Silver
Scene modes	Children, Night landscape, Night portrait, Panorama, Portrait, Sports, Sunset, Underwater, Landscape (scenery)
Image editing	Crop, Resizing
Photo effects	Black&White, Sepia, Vivid
White balance	Auto, Cloudy, Daylight, Incandescent, Shade
Shooting modes	Auto, Movie, Program, Scene
Camera playback	Movie, Single image, Slide show, Thumbnails
Self-timer delay	2, 10 s
Camera file system	DCF, Exif 2.3
On Screen Display (OSD) languages	DEU, ENG, ESP, FRE, ITA, JPN
Battery voltage	3.6 V
Battery capacity	895 mAh
Battery life (CIPA standard)	260 shots
Cables included	USB

Weight and Dimensions

Depth	28.2 mm
Width	104.9 mm
Height	58.9 mm
Weight	184 g
Weight (including battery)	206 g
