Panasonic Lumix DMC-TZ30 Operating Instructions

- 162 -
Keep the recorded still pictures and motion
pictures
The methods for copying still and motion pictures recorded with this camera to other
devices vary according to the file format (JPEG, MPO, AVCHD, MP4, Motion JPEG).
Follow the correct method for your device.
Copy by inserting the SD card into the recorder
You can copy pictures using Panasonic equipment (such as Blu-ray disc recorders) with
support for each file format.
Check the latest information about equipment that is compatible with this camera on the
following website.
• Note that the equipment described may not be available in certain countries and regions.
http://panasonic.jp/support/global/cs/dsc/ (This Site is English only.)
• See the instruction manual for the recorder for details for copying and
playing back.
32
3232
Dubbing playback pictures via AV cables (optional)
Videos that are played on this camera can be dubbed on media such as a disc, hard disk
or videotape using a device such as a video recorder. This method is useful as it allows
dubbing to be performed even with devices that are not compatible with high definition
images. Picture quality will be reduced from high definition to standard definition. Audio
will be monaural.
Connect camera to recorder
To recorder’s input socket
AV cable
(optional)
Start playback on camera
Start recording on recorder
• To stop recording (dubbing), stop the recording
on your recorder first before stopping the
playback on the camera.
●
Always use a genuine Panasonic AV cable (optional).
●
When using a TV with a 4:3 aspect ratio, always change the camera’s [TV Aspect]
setting (→59) to [4:3] before dubbing. Motion pictures copied in the [16:9] setting will
appear vertically stretched when viewed on a 4:3 TV screen.
●
For details on dubbing and playback methods, refer to your recorder’s operating
instructions.

Panasonic Lumix DMC-TZ30 Specifications

General

Megapixel	14.1 MP
Camera type	Compact camera
Sensor type	Live MOS
Image stabilizer	Yes
Total megapixels	15.3 MP
Image sensor size	1/2.33 \
Supported aspect ratios	3:2, 4:3, 16:9
Maximum image resolution	4320 x 3240 pixels
Still image resolution(s)	480 x 480, 640 x 360, 640 x 424, 640 x 480, 1536 x 1536, 1920 x 1080, 1920 x 1920, 2048 x 1360, 2048 x 1536, 2304 x 2304, 2560 x 1440, 2560 x 1712, 2560 x 1920, 2736 x 2736, 3072 x 1728, 3072 x 2048, 3072 x 2304, 3232 x 3232, 3648 x 2056, 3648 x 2432, 3648 x 2736, 4320 x 2432, 4320 x 2880, 4320 x 3240
Digital zoom	4 x
Optical zoom	20 x
Extra/Smart zoom	42.2 x
Focal length range	4.3 - 86 mm
Maximum aperture number	6.4
Minimum aperture number	3.3
Number of aspheric elements	3
Lens structure (elements/groups)	12/10
Maximum focal length (35mm film equiv)	480 mm
Minimum focal length (35mm film equiv)	24 mm
Focus	TTL
Focus adjustment	Auto
Normal focusing range	0.5 - ∞/2 - ∞ m
Auto focusing (AF) modes	Continuous Auto Focus, Tracking Auto Focus
Macro focusing range (tele)	1 - ∞ m
Macro focusing range (wide)	0.03 - ∞ m
Normal focusing range (tele)	2 - ∞ m
Normal focusing range (wide)	0.5 - ∞ m
Light metering	Centre-weighted, Evaluative (Multi-pattern), Spot
ISO sensitivity	100, 200, 400, 800, 1600, 3200, 6400, Auto
Light exposure modes	Aperture priority AE, Manual, Shutter priority AE
ISO sensitivity (max)	6400
ISO sensitivity (min)	100
Light exposure control	Program AE
Light exposure correction	± 2EV (1/3EV step)
Fastest camera shutter speed	1/2000 s
Slowest camera shutter speed	15 s
Flash modes	Auto, Forced off, Forced on, Red-eye reduction, Slow synchronization
Flash range (tele)	1 - 3.3 m
Flash range (wide)	0.6 - 6.4 m
Digital SLR	No
Power source type	Battery
Video resolutions	320 x 240, 640 x 480, 1280 x 720, 1920 x 1080 pixels
Video formats supported	AVCHD, M-JPEG, MOV, MP4
Maximum video resolution	1920 x 1080 pixels
Analog signal format system	NTSC, PAL
Audio system	Mono
Internal memory	12 MB
Compatible memory cards	SD, SDHC, SDXC
Field of view	100 %
Display diagonal	3 \
Display resolution (numeric)	460000 pixels
USB version	2.0
Product color	Silver
Scene modes	Children, Night landscape, Night portrait, Panorama, Portrait, Sports, Sunset, Underwater, Landscape (scenery)
Image editing	Crop, Resizing
Photo effects	Black&White, Sepia, Vivid
White balance	Auto, Cloudy, Daylight, Incandescent, Shade
Shooting modes	Auto, Movie, Program, Scene
Camera playback	Movie, Single image, Slide show, Thumbnails
Self-timer delay	2, 10 s
Camera file system	DCF, Exif 2.3
On Screen Display (OSD) languages	DEU, ENG, ESP, FRE, ITA, JPN
Battery voltage	3.6 V
Battery capacity	895 mAh
Battery life (CIPA standard)	260 shots
Cables included	USB

Weight and Dimensions

Depth	28.2 mm
Width	104.9 mm
Height	58.9 mm
Weight	184 g
Weight (including battery)	206 g
