Panasonic Lumix DMC-TZ40 User Manual

2 VQT4T06 (ENG)
Dear Customer,
We would like to take this opportunity to thank you for purchasing this Panasonic
Digital Camera. Please read these Operating Instructions carefully and keep
them handy for future reference. Please note that the actual controls and
components, menu items, etc. of your Digital Camera may look somewhat
different from those shown in the illustrations in these Operating Instructions.
Carefully observe copyright laws.
• Recording of pre-recorded tapes or discs or other published or broadcast
material for purposes other than your own private use may infringe copyright
laws. Even for the purpose of private use, recording of certain material may
be restricted.
Information for Your Safety
WARNING:
To reduce the risk of fire, electric shock or product damage,
• Do not expose this unit to rain, moisture, dripping or
splashing.
• Use only the recommended accessories.
• Do not remove covers.
• Do not repair this unit by yourself. Refer servicing to
qualified service personnel.
The socket outlet shall be installed near the equipment and shall be
easily accessible.
■
Product identification marking
Product Location
Digital camera Bottom
■
About the battery pack
CAUTION
• Danger of explosion if battery is incorrectly replaced. Replace
only with the type recommended by the manufacturer.
• When disposing the batteries, please contact your local
authorities or dealer and ask for the correct method of disposal.
• Do not heat or expose to flame.
• Do not leave the battery(ies) in a car exposed to direct sunlight for a
long period of time with doors and windows closed.

Panasonic Lumix DMC-TZ40 Specifications

General

Megapixel	18.1 MP
Camera type	Compact camera
Sensor type	MOS
Image stabilizer	Yes
Total megapixels	18.9 MP
Image sensor size	1/2.3 \
Image formats supported	JPG, MPO
Supported aspect ratios	4:3
Maximum image resolution	4896 x 3672 pixels
Still image resolution(s)	4896x3672\\r 4896x3264\\r 4896x2752\\r 4000x3000\\r 4000x2672\\r 4000x2248\\r 3664x3664\\r 3264x2448\\r 3264x2176\\r 3264x1840\\r 2992x2992\\r 2448x2448\\r 2560X1920\\r 2560x1712\\r 2560x1440\\r 2048X1536\\r 2048x1360\\r 1920x1920\\r 1920x1080\\r 1536x1536\\r 640x480\\r 640x424\\r 640x360\\r 480x480
Digital zoom	4 x
Optical zoom	20 x
Extra/Smart zoom	47.8 x
Focal length range	4.3 - 86 mm
Maximum aperture number	8
Minimum aperture number	3.3
Number of aspheric elements	9
Lens structure (elements/groups)	12/10
Maximum focal length (35mm film equiv)	560 mm
Minimum focal length (35mm film equiv)	24 mm
Normal focusing range	0.5 - ∞, 2 - ∞ m
Auto focusing (AF) modes	Continuous Auto Focus, Spot Auto Focus, Tracking Auto Focus
Macro focusing range (tele)	1 - ∞ m
Macro focusing range (wide)	0.03 - ∞ m
Normal focusing range (tele)	2 - ∞ m
Normal focusing range (wide)	0.5 - ∞ m
Light metering	Centre-weighted, Evaluative (Multi-pattern), Spot
ISO sensitivity	100, 200, 400, 800, 1600, 3200, 6400, Auto
Light exposure modes	Aperture priority AE, Manual, Shutter priority AE
ISO sensitivity (max)	6400
ISO sensitivity (min)	100
Light exposure control	Program AE
Light exposure correction	± 2EV (1/3EV step)
Fastest camera shutter speed	1/2000 s
Slowest camera shutter speed	30 s
Flash modes	Auto, Forced off, Forced on, Red-eye reduction, Slow synchronization
Flash range (tele)	1 - 3.3 m
Flash range (wide)	0.6 - 6.4 m
Power source type	Battery
Video resolutions	640 x 480, 1280 x 720, 1920 x 1080 pixels
Video formats supported	AVCHD, MP4
Maximum video resolution	1920 x 1080 pixels
Analog signal format system	NTSC, PAL
Resolution at capture speed	1280x720@25fps, 1280x720@50fps, 1920x1080@25fps, 1920x1080@50fps, 640x480@25fps
Memory slots	1
Internal memory	12 MB
Compatible memory cards	SD, SDHC, SDXC
Field of view	100 %
Display diagonal	3 \
Display resolution (numeric)	920000 pixels
USB version	-
HDMI connector type	Micro
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Scene modes	Children, Night landscape, Night portrait, Panorama, Pet, Portrait, Sports
Image editing	Crop, Resizing
Photo effects	Art, Black&White, Sepia, Vivid
White balance	Auto, Cloudy, Daylight, Incandescent, Shade
Camera playback	Single image, Slide show
Self-timer delay	2, 10 s
Camera file system	DCF, Exif 2.3
On Screen Display (OSD) languages	ARA, CHI (TR), ENG, FRE, PER, RUS, THA
Battery voltage	3.6 V
Battery capacity	1250 mAh
Battery life (CIPA standard)	300 shots
Product color	Black
Cables included	USB
Bundled software	PHOTOfunSTUDIO 9.1 PE

Weight and Dimensions

Depth	27.7 mm
Width	108.3 mm
Height	58.9 mm
Weight	172 g
Weight (including battery)	198 g
