Panasonic Lumix DMC-ZS25 User Manual

VQT4P14
Others
Using the AC adaptor (optional) and DC coupler
(optional) instead of the battery
- 145 -
Others
By using the AC adaptor (optional) and DC coupler (optional), you can record and play
back without worrying about the remaining battery charge.
The optional DC coupler can only be used with the designated Panasonic AC adaptor.
Insert DC coupler instead of
battery
Open DC coupler cover
• If difficult to open, with the card/
battery door open, press the DC
coupler cover from the inside to
open it.
Close the door and slide the
release lever to the [LOCK]
position
Plug AC adaptor into power
outlet
Connect AC adaptor to DC IN
socket of DC coupler
●
Always use a genuine Panasonic AC adaptor (optional).
●
Use the AC adaptor and DC coupler specifically for this camera. Using other adaptors
or couplers could cause camera failure.
●
It may not be possible to install camera on a tripod or unipod when the DC coupler is
connected, depending on the type of tripod or unipod.
●
The camera cannot be stood up when the AC adaptor is connected. If you are leaving
the camera on a surface as you work, it is recommended to set it on a soft cloth.
●
When the AC adaptor is connected, always remove the AC adaptor when opening the
card/battery door.
●
Remove the AC adaptor and DC coupler when not in use and close the DC coupler
cover.
●
Also read the AC adaptor and DC coupler operating instructions.
DC IN socket
DC coupler
DC coupler
cover
Confirm the direction
of the connector and
insert it straight into the
socket.
AC adaptor

Panasonic Lumix DMC-ZS25 Specifications

General

Megapixel	16.1 MP
Camera type	Compact camera
Sensor type	MOS
Image stabilizer	Yes
Total megapixels	17.5 MP
Image sensor size	1/2.33 \
Maximum image resolution	- pixels
Still image resolution(s)	-
Digital zoom	4 x
Optical zoom	20 x
Focal length range	4.3 - 86 mm
Maximum aperture number	6.4
Minimum aperture number	3.3
Number of aspheric elements	9
Lens structure (elements/groups)	12/10
Maximum focal length (35mm film equiv)	560 mm
Minimum focal length (35mm film equiv)	28 mm
Focus adjustment	Auto
Auto focusing (AF) modes	Continuous Auto Focus, Single Auto Focus, Spot Auto Focus
Macro focusing range (tele)	1 - ∞ m
Macro focusing range (wide)	0.03 - ∞ m
Light metering	Centre-weighted, Evaluative (Multi-pattern), Spot
ISO sensitivity	100, 200, 400, 800, 1600, 3200
Light exposure modes	Aperture priority AE, Manual, Shutter priority AE
ISO sensitivity (max)	3200
ISO sensitivity (min)	100
Light exposure control	Program AE
Light exposure correction	± 2EV (1/3EV step)
Fastest camera shutter speed	1/2000 s
Slowest camera shutter speed	15 s
Flash modes	Auto, Forced off, Forced on, Red-eye reduction, Slow synchronization
Flash range (tele)	1 - 3.3 m
Flash range (wide)	0.6 - 6.4 m
Power source type	Battery
Video resolutions	640 x 480, 1280 x 720, 1920 x 1080 pixels
Motion JPEG frame rate	30 fps
Video formats supported	AVCHD, MP4
Maximum video resolution	1920 x 1080 pixels
Audio system	Mono
Memory slots	1
Internal memory	90 MB
Compatible memory cards	SD, SDHC, SDXC
Field of view	100 %
Display diagonal	3 \
Display resolution (numeric)	460000 pixels
Viewfinder type	Not available
USB version	2.0
HDMI connector type	Mini
Wi-Fi	No
Scene modes	Children, Cuisine, Night, Night landscape, Night portrait, Pet, Portrait, Sports, Sunset, Underwater, Landscape (scenery)
Image editing	Crop, Resizing
Photo effects	Black&White, Neutral, Positive film, Sepia, Vivid
White balance	Auto, Cloudy, Daylight, Incandescent, Shade
Self-timer delay	2, 10 s
On Screen Display (OSD) languages	DEU, ENG, ESP, FRE, ITA, JPN, POR
Battery voltage	3.6 V
Battery capacity	895 mAh
Battery life (CIPA standard)	260 shots
Product color	Black
Cables included	USB

Weight and Dimensions

Depth	28.7 mm
Width	104.9 mm
Height	58.9 mm
Weight	171 g
Weight (including battery)	193 g
