VQT4P14
Others
Q&A Troubleshooting
- 152 -
Try checking these items (→152 - 158) first.
If the problem persists, performing [Reset] in the [Setup] menu may resolve the issue.
(Note that except for some items such as [Clock Set], all settings are returned to their
values at the time of purchase.)
Battery, power
The charging lamp turns off or flashes before the battery is fully charged.
Charging is being performed in a place with extremely high or low temperature.
Reconnect the USB connection cable (supplied) and retry charging in a place where ambient
temperature is 10 °C to 30 °C (50 °F to 86 °F) (temperature conditions also apply to the battery
itself). (When the USB connection cable is reconnected after the battery is fully charged, the
charging lamp will light for approximately 15 seconds.)
Camera does not work even if the camera is turned on.
Camera switches off as soon as the camera is turned on.
Battery is not inserted correctly (→11), or needs recharging.
This unit is turned off automatically.
If you connect to a TV compatible with VIERA Link with an HDMI mini cable (optional) and turn off
the TV with the remote control for the TV, this unit also turns off.
→ If you are not using VIERA Link, set [VIERA Link] to [OFF]. (→51)
[Auto Power Off] is activated. (→49)
Recording
Cannot record pictures.
Built-in memory/card is full.
→ Free space by deleting unwanted pictures. (→40)
Recorded pictures look white.
Lens is dirty (fingerprints, etc.).
→ Turn the camera on to extract lens barrel, and clean lens surface with a soft, dry cloth.
Lens is foggy. (→5)
Recorded pictures are too bright/too dark.
Adjust the exposure. (→64)
[Min. Shtr Speed] is set to fast speeds, e.g. [1/250]. (→103)
Some pictures are taken when I press the shutter button just once.
Camera is set to use [Auto Bracket] or [Burst].
Focus not aligned correctly.
Not set to mode appropriate for distance to subject. (Focus range varies according to recording
mode.)
Subject outside of focus range.
Caused by jitter or subject movement.
Recorded pictures are blurred. Optical Image Stabilizer ineffective.
Shutter speed is slower in dark locations and Optical Image Stabilizer is less effective.
→ Hold camera firmly with both hands, keeping arms close to body.
Use a tripod and the self-timer (→63) when using slower shutter speed with [Min. Shtr Speed].

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Panasonic Lumix DMC-ZS25 and is the answer not in the manual?

Panasonic Lumix DMC-ZS25 Specifications

General IconGeneral
Megapixel16.1 MP
Camera typeCompact camera
Sensor typeMOS
Image stabilizerYes
Total megapixels17.5 MP
Image sensor size1/2.33 \
Maximum image resolution- pixels
Still image resolution(s)-
Digital zoom4 x
Optical zoom20 x
Focal length range4.3 - 86 mm
Maximum aperture number6.4
Minimum aperture number3.3
Number of aspheric elements9
Lens structure (elements/groups)12/10
Maximum focal length (35mm film equiv)560 mm
Minimum focal length (35mm film equiv)28 mm
Focus adjustmentAuto
Auto focusing (AF) modesContinuous Auto Focus, Single Auto Focus, Spot Auto Focus
Macro focusing range (tele)1 - ∞ m
Macro focusing range (wide)0.03 - ∞ m
Light meteringCentre-weighted, Evaluative (Multi-pattern), Spot
ISO sensitivity100, 200, 400, 800, 1600, 3200
Light exposure modesAperture priority AE, Manual, Shutter priority AE
ISO sensitivity (max)3200
ISO sensitivity (min)100
Light exposure controlProgram AE
Light exposure correction± 2EV (1/3EV step)
Fastest camera shutter speed1/2000 s
Slowest camera shutter speed15 s
Flash modesAuto, Forced off, Forced on, Red-eye reduction, Slow synchronization
Flash range (tele)1 - 3.3 m
Flash range (wide)0.6 - 6.4 m
Power source typeBattery
Video resolutions640 x 480, 1280 x 720, 1920 x 1080 pixels
Motion JPEG frame rate30 fps
Video formats supportedAVCHD, MP4
Maximum video resolution1920 x 1080 pixels
Audio systemMono
Memory slots1
Internal memory90 MB
Compatible memory cardsSD, SDHC, SDXC
Field of view100 %
Display diagonal3 \
Display resolution (numeric)460000 pixels
Viewfinder typeNot available
USB version2.0
HDMI connector typeMini
Wi-FiNo
Scene modesChildren, Cuisine, Night, Night landscape, Night portrait, Pet, Portrait, Sports, Sunset, Underwater, Landscape (scenery)
Image editingCrop, Resizing
Photo effectsBlack&White, Neutral, Positive film, Sepia, Vivid
White balanceAuto, Cloudy, Daylight, Incandescent, Shade
Self-timer delay2, 10 s
On Screen Display (OSD) languagesDEU, ENG, ESP, FRE, ITA, JPN, POR
Battery voltage3.6 V
Battery capacity895 mAh
Battery life (CIPA standard)260 shots
Product colorBlack
Cables includedUSB
Weight and Dimensions IconWeight and Dimensions
Depth28.7 mm
Width104.9 mm
Height58.9 mm
Weight171 g
Weight (including battery)193 g
