Preparations
Names and Functions of Main Parts
SQW0195
- 12 -
16 Viewfinder (LVF) (→14)
In this manual, “viewfinder” is used to indicate the LVF.
17 Diopter adjustment dial (→15)
Turn the dial to adjust the focus in the viewfinder.
18 Eye Sensor
The display is automatically switched to viewfinder when your eye or an object moves close to
the viewfinder. (→14)
19 [LVF] button (→14) / [Fn2] button (→14, 134)
Use this to switch display between viewfinder and LCD monitor. ([LVF] button)
Use this button to operate a registered function. ([Fn2] button)
20 Monitor (→66, 67, 279)
21 Charging lamp (Red) (→20)
Wi-Fi
®
connection lamp (Blue) (→190)
The color of the lamp differs depending on the function.
22 Strap eyelet (→16)
23 [HDMI] socket (→261, 263)
Do not connect any other cables except the HDMI micro cable. Doing so may cause
malfunction.
24 [AV OUT/DIGITAL] socket (→19, 261, 267, 272, 275)
This socket is also used when charging the battery.
16 18 19 22
23
24
20 2117
