Panasonic MC-CG902-00 - Hose & Attachments

2.3. Hose & Attachments
2.3.1. Exploded View
2.3.2. Parts List
Ref. No. Part No. Part Name & Description Quantity Remarks
1 AC94PCHKZV06 HOSE ASSEMBLY 1
2 AC96RAKZZV06 FLOOR BRUSH 1
3 AC60RAKZZV06 CREVICE TOOL 1
4 AC86RAKZZV06 FABRIC BRUSH 1
5 AC88RAKZZV06 DUSTING BRUSH 1
6 AC05PSUZV06 HOSE ONLY 1
7 AC92PCAZZV06 SWIVEL ASSY 1
8 AC22PAFZZV06 HOSE ADAPTER 1
9 AC98PSTZV06 CURVED PIPE INIT 1
10 AXTN4+12BFY SCREW 5 SHIPPED 10 PER PACKAGE
11 AC31TBMVZ0U0 ORNAMENTAL PLATE 1
12 AC93BSTZV06 HANDLE ASSEMBLY 1
13 AC09ESTZ000 SLIDE SWITCH 1
14 AC99EAVKZVU7 SLIDE KNOB 1
15 AC54PAPAZV06 CONTROL SUCTION 1
16 AMC415-2093 SPRING WAND LOCK 1
17 AC37GSTZV06 WIRE HARNESS 1
18 AC97PAENZV06 UPPER WAND 1
19 AC99PAKSZV06 LOWER WAND 1
20 AMC725-419 SPRING WAND LOCK 1 SHIPPED 10 PER PACKAGE
8
MC-CG902-00
