DISPOSAL OF BATTERY
The battery for power failure alarm is an article for consumption. The battery life is approximately 3
years. The buzzer and alarm lamp cannot be activated at the power failure and the stored items may be
influenced if the battery is left as it is for more than 3 years. It is recommended that the battery is
replaced ahead of time.
For the replacement of the battery, contact our sales representative or agent.
Location of a nickel-metal-hydride battery
This unit is provided a nickel-metal hydride battery for the power failure alarm. The battery is located in
the control box behind the control panel. (Fig. 1)
The high voltage components are enclosed in the control box. The control box cover should be
removed by a qualified engineer or a service personnel only to prevent the electric shock.
Disposal of nickel-metal-hydride battery
1.
Turn off the power switch, battery switch and disconnect the power supply plug.
2.
Remove 4 fixing screws on the side panel and take out the side panel. (Fig. 2)
3.
Loosen 2 upper screws, and remove 2 side screws, and remove a control box cover. (Fig. 3)
4.
Remove 2 screw fixing the battery mounting plate securing the battery and then disconnect the
connector. (Fig. 4)
5.
Follow the procedure for recycling or proper disposal.
Fig. 3
Fig. 1 Fig. 2
Fig. 4
Control box
side panel
Control box
cover
Connecter
Battery
Battery
mounting
plate
