Panasonic MDF-U5312 - Performance

31
SPECIFICATIONS
Product name
Biomedical Freezer
MDF-U5312
External dimensions W804 mm x D772 mm x H1802 mm
Internal dimensions W658 mm x D607 mm x H1272 mm
Effective capacity 482 L
Exterior Painted steel
Interior Styrol resin
Insulation Rigid polyurethane foamed-in place
Outer door Painted steel
Lock 1
Caster 4
Leveling foot 2
Evaporator Tube on sheet type (also used as a shelf)
Access port Diameter 30 mm, 1 on back side
Condenser Wire and tube type
Compressor Hermetic rotary type, 400 W
Refrigerant R-404A
Temperature controller Microcomputer control system
Temperature display Digital display (between -50
o
C and +50
o
C)
Temperature sensor Thermistor sensor
Temperature alarm Flash of digital indicator and alarm lamp, Buzzer, (Remote alarm)
Accessories
1 set of key, 1 scraper
6 small baskets for upper chamber; W290 x D536 x H136 (mm)
4 large baskets for lower chamber; W290 x D536 x H238 (mm)
Weight
134
kg
Battery
For power failure alarm, Nickel-metal-hydride battery,
DC 6 V, 1100 mAh, Automatic charge (5HR-AAC)
Optional component
Temperature recorder (MTR-4015LH)
Temperature recorder (MTR-G85A, MTR-G85C)
Recorder fixing for temperature recorder (MPR-S30, MPR-S7)
Interface board (MTR-480, MTR-L03)
Data acquisition system (MTR-5000)
Note : Design or specifications will be subject to change without notice.
• Refer to the updated catalog when ordering an optional component.
• The battery for power failure alarm is an article for consumption. It is recommended that the battery will
be replaced about every 3 years. Contact our sales representative or agent at the time of replacement of
the battery for recycling.
• Fan motor is expendable supplies. Exchange it for about every 6 years. Contact our sales
representative or agent at the time of replacement of the fan motor.
