Panasonic MINAS A4 - Page 4

PLC Connection Guide
Diagram 2
cMT Series
cMT-SVR
mTV
mTV
MT-iE
MT8070iE / MT6070iE / MT8100iE / MT8121iE / MT8150iE /
MT8071iE / MT6071iE / MT8072iE / MT6072iE / MT8073iE /
MT8101iE / MT8102iE / MT8103iE
MT-XE
MT8121XE / MT8150XE / MT8090XE
HMI PLC
COM1
RS232 8P
Mini-DIN Male
RS232
9P Male
Rx 2 3 TXD
Tx 3 5 RXD
GND 5 4 GND
Diagram 3
MT-iE
MT8050iE
MT-iP
MT6051iP / MT6071iP / MT8071iP
HMI PLC
COM1
RS232 8P
Mini-DIN Male
RS232
9P Male
Rx 9 3 TXD
Tx 6 5 RXD
GND 5 4 GND
