- 7 -
NA-F60A6, F70A6, F756A, F70G6, F70G6P, F70X6, F806X
3.3 Function control with fuzzy sensor
Clothes quantity checking, wash level indication and detergent consumption indication with Fuzzy Logic System.
1. Check clothes quantity and specify the amount of detergent.
2. Temperature checking.
Check temperature in the atmosphere when the machine starts.
In case of low temperature, wash timer and spin timer are extended
automatically, so that washed clothes are as clean as washing in
high temperature.
1. Wash timer and spin timer with checked clothes quantity.
2. Additional wash timer and spin timer as temperature increases.
Rotate clockwise
stop
< Motor Status >
Rotate
anti-clockwize
Turn Switch “ON”
Press “Start” button
1. Check clothes quantity
2. Check ambient temperature
A. Check clothes quantity
B. Control wash time
C. Control spin time
Supply water to a proper level
WASH
RINSE
SPIN
Switch will automatically cut the
power current “OFF”
< Checking Method >
Check cross pressure at the capacitor
while the Pulsator operates without water.
stop
Rotate clockwise
stop
Rotate
anti-clockwize
stop
Rotate clockwise
stop
Rotate
anti-clockwize
stop
High
3.0 Kg and more
Medium
1.2 Kg ~ 3.0 Kg
Low
0 Kg ~ 1.2 Kg
Wash Timer 12 min 12 min 9 min
Spin Timer 6 min 6 min 5 min
External Temp. 25°C 15°C 5°C 30°C
Wash Timer +0 min +2 min +3 min -1 min
Spin Timer +0 min +1 min +2 min +0 min
