- 9 -
NA-F60A6, F70A6, F756A, F70G6, F70G6P, F70X6, F806X
4.2 Connect the water supply hose
4.3 Install washing machine to steady
4.4 Child Lock program
Adjust height of leg
If the floor is largely inclined.
Use board or
a like for prop
up under leg
of washing
machine.
1. Turn the adjustable leg knob towards (Loosen)
direction to loose it.
2. Turn the adjustable leg to adjust the levelness.
2.1 When increasing height, turn adjustable leg
towards (Loosen) direction.
2.2 When decreasing height, turn adjustable leg
towards (Tighten) direction.
3. Turn the adjustable leg knob towards (Tighten)
direction to tighten it.
[ Note ]
- Firmly tighten part B of the water tap adaptor,
otherwise, water leakage will result.
- When the hose must be reinstalled (after you remove).
For example, turn B to the left until about 4 min., of the
thread becomes visible, then carry out the procedure
described above.
- If a water tap adaptor is already connected, replace
with the attached new one.
Press the [ POWER OFF/ON ] button for at least
5 seconds. The buzzer sounds (2 times for setting)
and the [ CHILD LOCK ] indication turns on.
Less than
Open lid
Close lid Buzzer offBuzzer on
Buzzer on and
abnormal alarm
Water drain
Unplug the power
cord from the
outlet and re-plug
it again after
5 seconds
10 sec.
More than
10 sec.
Water faucet
Water supply
hose cover
A
B
Screw (4)
Water tap
adaptor
Lever
Approx. 4 mm
B
Adjustable leg knob
Adjustable leg
Loosen
Tighten
To raise
To lower
To Next Page
