Panasonic NA-S106G1

47
Others
6SHFL¿FDWLRQV
Model No. NA-S106X1 NA-S106G1
Rated voltage 220 - 240 V
Rated frequency 50 Hz
Maximum energy
rated power input
1700 - 1990 W
Heating energy rated
power input
For washing
For drying
1610 W
1530 W (230 V)
Maximum spin speed 1200 r/min
Product dimensions 596 mm (W) × 560 mm (D) × 845 mm (H)
Product weight 68 kg
Maximum wash
capacity (Dry cloth)
10 kg 10 kg
Maximum dry
capacity (Dry cloth)
6 kg 6 kg
Water consumption
Refer to “Power and Water Consumption”.
( P. 46)
Pressure of tap water 0.03 - 1 MPa
 Check the power supply
The rated power of the
appliance is shown on the name
plate. Make sure it matches the
VSHFL¿FDWLRQVRI\RXUUHVLGHQFH
Name plate
NA-S106X1_EN_MY_VI.indb 47 2017-11-20 17:40:26
