Part names
Checking Your Washing Machine
Detergent drawer (P. 12)
Accessories
Control panel
(P. 10)
DrumDoor
Door seal
Drain filter cover
(P. 35)
Hinge
Water inlet (P. 50)
Anchor bolts
(P. 48)
Drain hose
(P. 49, 50)
Power cord and plug
*
Adjustable feet
(P. 48)
 Elbow (P. 50)  Cover caps (4) (P. 48)
 Water supply hose (P. 49, 50)  Bottom cover (1) /Screw (1) (P. 47)
* The plug shape varies
with the region.
7
