17
Rubber gasket set
Replace gaskets if they crack, lose their pliability
or, for any other reasons which allow steam to
escape from between the container and the lid.
Meshlter
Replace the lter, if foreign matter which
clog the lter cannot be removed, even after
you scrub with a cleaning brush, etc.
The lter can be
removed by pulling
rmly on it.
APB97-480-0U
Lid cover
Remove gaskets
For replacement parts, please
contact an authorized dealer.
Part name Part No.
Rubber gasket set APH65-6131H1
Mesh lter APB97-480-0U
Remove lid, unscrew 3 tapping screws and remove
the lid cover.
Exchange the gaskets and then place the lid cover
back and secure with the tapping screws.
Replacement of Parts
Model No.
NC-EG4000 NC-EG3000 NC-EG2200
Power supply 220 V 50 Hz
Power consumption 700 W
Average power consumption
in keeping warm (approx.)
Amount of water: maximum
Room temperature: 20°C
at 98
49 Wh
45 Wh 40 Wh
at 90
43 Wh
39 Wh 33 Wh
at 80
35 Wh
31 Wh 27 Wh
at 70
30 Wh
26 Wh 23 Wh
Dimensions
(when the handle is
tilted)
Height (approx.)
32.4 cm
27.5 cm 23.8 cm
Width (approx.)
21.7 cm
21.7 cm 21.7 cm
Depth (approx.)
28.7 cm
28.7 cm 28.7 cm
Weight (including power cord) (approx.)
2.2 k
g
2.1 k
g
2.0 k
g
Rated capacity (approx.)
4.0 L
3.0 L 2.2 L
Specications
* Under certain conditions, such as at very high altitudes and in intense cold, the unit may not function
properly. Please avoid using the unit in such conditions.
* If the unit is not used during cold conditions, make sure to empty it of water. The water left in the inner
container may freeze causing damage.
Replacement of Parts / Specications
