9.2. PARTS LIST
NOTE:
1. When ordering replacement part(s), please use part number(s) shown in this part list.
Do not use description of the part.
2. Important safety notice:
Components identified by
mark have special characteristics important for safety.
When replacing any of these components, use only manufacture’s specified parts.
Ref. No. Part No. Part Name & Description Pcs/Set Remarks
1 F00069660AP CAUTION LABEL 1
3 F00338F00RP FUSE LABEL 1
4 F10016P40AP BASE 1
5 F10084T00APS RUBBER FOOT 4
6 F10095W10SAP CABINET BODY 1 SE995S
6 F10095W20SAP CABINET BODY 1 SD985S
6 F10095W20BAP CABINET BODY 1 ST965S
7 F200ABP30HAP OVEN 1 SE995S
7 F200ABP50HAP OVEN 1 SD985S,ST965S
8 F2055BP20AP COVER 1 SE995S
8 F20555K00AP COVER 1 SD985S,ST965S
9 F2131BP30AP PULLY SHAFT 1 SE995S
9 F21315Y00AP PULLY SHAFT 1 SD985S,ST965S
10 F2177-F80 WASHER 1
11 F290D9R00AP ROLLER RING(U) 1 SE995S
11 F290D9330AP ROLLER RING(U) 1 SD985S,ST965S
12 F30206G30AP DOOR HOOK 1
14 F31366G30AP HOOK LEVER A 1
15 F31376G30AP HOOK LEVER B 1
16 F31386G30AP HOOK LEVER C 1
17 F400A5Y00AP FAN MOTOR 1 AC120V,SINGLE PHASE,60Hz
18 F40084T00AP FAN BLADE 1
19 F4025BP20AP AIR GUIDE A 1
20 F40264T60APG AIR GUIDE B 1
21 F41445W00AP ORIFICE 1
22 F64508660AP SENSOR COVER B 1
24 F65434W00AP SENSOR COVER C 1
25 J607S4M00AP STEAM SENSOR 1
26 F612EBP20AP LAMP (U) 1 LED LAMP INSIDE
27 J61415G10XN MICRO SWITCH 1 (PRIMARY INTERLOCK SWITCH)
28 F61415U30XN MICRO SWITCH 1 (SECONDARY INTERLOCK SWITCH)
29 F61456N60AP THERMAL CUTOUT 1 150°C OPEN,-20°C CLOSE
31 F61785U30XN MICRO SWITCH 1 (MONITOR INTERLOCK SWITCH)
32 F606Y9X90AP H.V.INVERTER (U) 1
33 F65856K50AP INVERTER BRACKET 1
34 2M261-M32JP MAGNETRON 1 SE995S
34 2M261-M32KLP MAGNETRON 1 SD985S,ST965S
35 F62308F20AP FUSE 1 20A
36 F62315G10XN FUSE HOLDER 1
38 F63265G60AP TURNTABLE MOTOR 1
39 F900C4T00AP AC CORD W/PLUG 1
40 F66626G10AP GROUNDING PLATE 1
41 XTWFL4+12T SCREW 4 FOR MAGNETRON
42 F90804W00AP CANOE CLIP 1 FOR COVER (SD985S,ST965S)
43 XTTBFE4T10A0 SCREW 5 FOR CABINET BODY
44 XTTFL4+6BN SCREW 2 FOR CABINET BODY SIDE (SE995S,SD985S)
44 XTTFA4+6BFZ SCREW 2 FOR CABINET BODY SIDE (ST965S)
48 F82575W00AP DOOR OPENING BRACKET 1
52 F0006BP30RP CAUTION LABEL 1 ST965S
56 F0334BQ40RP MENU LABEL 1 ST965S
56 F0446BP30RP FUNCTION LABEL 1 SE995S
29
NN-SE995S / NN-SD985S / NN-ST965S
