Panasonic NN-SD985S - Parts List

10.4. PARTS LIST
10.4.1. NN-SE995S
Ref. No. Part No. Part Name & Description Pcs/Set Remarks
BZ210 L0DDEA000014 BUZZER 1 2.0KHz
DISP110 L5AYAYY00314 LCD 1
DISP HOLDER F6617BP20AP LCD HOLDER 1
CX320 H2A8004A0038 CERAMIC RESONATOR 1 8.0MHz
F67525E40XN DIFFUSION SHEET 1
VA1 D4EAY2710001 VARISTOR 1 270V
IC1 MNBP3F31AAX L.S.I. 1
IC10 C0DBGYY05981 IC 1 VOLTAGE-STABILIZED
IC25 C0DBBYY00073 IC 1
IC42 B1HBGFF00007 IC 1
IC380 C3EBDC000063 IC 1
IC480 C0ABBA000230 IC 1
PC25 B3PAA0000302 IC 1
RL1 K6B1AYY00129 POWER RELAY 1
T10 G4DYA0000681 SWITCH POWER SUPPLY 1 120V
FUSE1 K5G402YA0159 FUSE 1 4A,250V
10.4.2. NN-ST965S
Ref. No. Part No. Part Name & Description Pcs/Set Remarks
BZ210 L0DDEA000014 BUZZER 1 2.0KHz
DISP110 L5AYAYY00302 LCD 1
DISP HOLDER F6617BP80AP LCD HOLDER 1
F6752BP80AP DIFFUSION SHEET 1
VA1 D4EAY2710001 VARISTOR 1 270V
IC1 MNBP8F50AAB L.S.I. 1
IC10 C0DBGYY05981 IC 1 VOLTAGE-STABILIZED
IC25 C0DBBYY00073 IC 1
IC480 C0ABBA000230 IC 1
PC25 B3PAA0000302 IC 1
RL1 K6B1AYY00129 POWER RELAY 1
T10 G4DYA0000681 SWITCH POWER SUPPLY 1 120V
FUSE1 K5G402YA0159 FUSE 1 4A,250V
10.4.3. NN-SD985S
Ref. No. Part No. Part Name & Description Pcs/Set Remarks
BZ210 L0DDEA000014 BUZZER 1 2.0KHz
DISP110 L5AYAYY00286 LCD 1
DISP HOLDER F66175W00AP LCD HOLDER 1
F67525E40XN DIFFUSION SHEET 1
VA1 D4EAY2710001 VARISTOR 1 270V
IC1 MN90F23AA1 L.S.I. 1
IC10 C0DBGYY05981 IC 1 VOLTAGE-STABILIZED
IC25 C0DBBYY00073 IC 1
IC480 C0ABBA000230 IC 1
PC25 B3PAA0000302 IC 1
RL1 K6B1AYY00129 POWER RELAY 1
T10 G4DYA0000681 SWITCH POWER SUPPLY 1 120V
FUSE1 K5G402YA0159 FUSE 1 4A,250V
RE80 EVEJ1HF2224M REVOLVING ENCODER 1
SW1-SW11 EVQ11L05R SWITCH 11
44
NN-SE995S / NN-SD985S / NN-ST965S
01/15
S-BP1,S-BP3
