6.2. PARTS LIST
NOTE:
1. When ordering replacement part(s), please use part number(s) shown in this part list.
Do not use description of the part.
2. Important safety notice:
Components identified by
mark have special characteristics important for safety.
When replacing any of these components, use only manufacture’s specified parts.
NOTE:
“A” parts are supplied by MOBU (Japan)
“F” parts are supplied by PHAMOS (China)
Ref. No. Part No. Part Name & Description Pcs/Set Remarks
1 F00064W70AP CAUTION LABEL 1 APH
1 F00067600CP CAUTION LABEL 1 CPH
3 F00338F00AP FUSE LABEL 1
4 F10016P40AP BASE 1
5 F10084T00AP RUBBER FOOT 4
6 F110D5W10SAP CABINET BODY 1 SD997S APH,SN977S APH
6 F110D6G10SAP CABINET BODY 1 SD997S CPH
6 F110D5W20SAP CABINET BODY 1 SD987S/SB APH,SD967S APH, SN957S APH,SN947S APH
7 F200A8D00AP OVEN 1
8 F20555K00AP COVER 1
9 F21315Y00AP PULLY SHAFT 1
10 F2177-F80 WASHER 1
11 F290D9330AP ROLLER RING(U) 1
12 F3020-1200 DOOR HOOK 1
14 F3136-1200 HOOK LEVER A 1
15 F31374650AP HOOK LEVER B 1
16 F31384650AP HOOK LEVER C 1
17 F400A8F00AP FAN MOTOR 1 AC120V,SINGLE PHASE,60Hz
18 F40084T00AP FAN BLADE 1
19 F40254W00AP AIR GUIDE A 1
20 F40264T60APG AIR GUIDE B 1
21 F41445W00AP ORIFICE 1
22 F64508660AP SENSOR COVER B 1
24 F65434W00AP SENSOR COVER C 1
25 A607S4M00AP STEAM SENSOR 1
26 F612E5Y30AP INCANDESCENT LAMP (U) 1 125V,60Hz
27 J61415G10XN MICRO SWITCH 1 (PRIMARY LATCH SWITCH)(V-15G-3C25)
28 J61414T00AP MICRO SWITCH 1 (SECONDARY LATCH SWITCH)(D3V-16G-3C25)
29 F61456N60AP THERMAL CUTOUT 1 150°C/-20°C
31 F61785U30XN MICRO SWITCH 1 (SHORT SWITCH)(D3V-1G-2C25)
32 F606Y8M00AP H.V.INVERTER (U) 1
33 F65856K50AP INVERTER BRACKET 1
34 2M261-M32KLP MAGNETRON 1 APH
34 2M261-M32JP MAGNETRON 1 CPH
35 F62308F20AP FUSE 1 20A
37 F692Y8F00APX NOISE FILTER 1
38 F63265G60AP TURNTABLE MOTOR 1
39 F900C4T60CP AC CORD W/PLUG 1 APH
39 F900C8E00CP AC CORD W/PLUG 1 CPH
40 F66626G10AP GROUNDING PLATE 1
41 XTWFA4+12T SCREW 4 FOR MAGNETRON
42 F90804W00AP CANOE CLIP 1 FOR COVER
43 XTTBFE4T12A0 SCREW 5 FOR CABINET BODY
44 XTTFA4+6BN SCREW 2 FOR CABINET BODY SIDE
46 F02445Y00AP CAUTION LABEL 1 SD997S APH/CPH,SD987S/SB APH,SN977S APH
47 F03347B60AP MENU LABEL 1 SD997S APH,SD987S/SB APH,SD967S APH
47 F03347B60CP MENU LABEL 1 SD997S CPH
48 F82574U00AP DOOR OPENING BRACKET 1 SD967S APH,SN947S APH
48 F82575W00AP DOOR OPENING BRACKET 1 EXCEPT SD967S APH & SN947S APH
49 F04467D00AP FUNCTION LABEL 1 SD997S APH,SD987S/SB APH,SD967S APH
49 F04467D00CP FUNCTION LABEL 1 SD997S CPH
50 F00067C50AP CAUTION LABEL 1 APH
50 F00067C50CP CAUTION LABEL 1 CPH
51 F11406G00AP LEVER STOPPER 1 SD997S APH/CPH,SD987S/SB APH,SN977S APH
