7.6. PARTS LIST
7.6.1. NN-SD997S APH/CPH,SD987S/SB APH
Ref. No. Part No. Part Name & Description Pcs/Set Remarks
BZ210 L0DDEA000014 BUZZER 1 2.0KHz
C13 AECETS1C100B AL CHEM CAPACITOR 1 10µF/16V
C111 ECEA1EKS101I AL CHEM CAPACITOR 1 100µF/25V
C10 AECETK1V102B AL CHEM CAPACITOR 1 1000µF/35V
C482 AECETS1H010B AL CHEM CAPACITOR 1 1µF/50V
C483 AECETS1HR47B AL CHEM CAPACITOR 1 0.47µF/50V
C485 AECETS1H2R2B AL CHEM CAPACITOR 1 2.2µF/16V
CX320 EFOEC8004A4 CERAMIC RESONATOR 1 8.0MHz
DISP A2BB00000150 VACUUM FLUORESCENCE DISPLAY 1
DISP HOLDER F66176Z00AP LCD HOLDER 1
F67528P00AP DIFFUSION SHEET 1
D40,D225,D220,D222,D223 MA2C19600E DIODE 5
D10-D13,D110,D111 B0EAKT000025 DIODE 6
D100 MA2C700A0F DIODE 1
D130-D133 AE3294UBCA7 LED 4
IC1 MN101C88DAG L.S.I. 1
IC10 C0CAADG00060 IC 1
IC350 C0EBH0000264 IC 1
IC480 C0ABBA000230 IC 1
Q131 B1BAAJ000003 TRANSISTOR 1
D25 D4EAY271A036 ZENER RESISTOR 1 270V
D26,D27 D4EAY112A036 ZENER RESISTOR 2 1100V
RY1 AEBGJQC25F18 POWER RELAY 1
RY2 K6B1AZA00011 POWER RELAY 1
T10 G4C3AAD00006 LOW VOLTAGE TRANSFORMER 1 120V
VZ490 D3BB6103A006 VARISTOR 1
RE80 EVEJ1HF2224B REVOLVING ENCODER 1
SW40-SW44,SW46-SW51 EVQ11L05R SWITCH 11
ZD110 B0BA3R500006 ZENER DIODE 1
ZD220 B0BA01100004 ZENER DIODE 1
7.6.2. NN-SD967S APH
Ref. No. Part No. Part Name & Description Pcs/Set Remarks
BZ210 L0DDEA000014 BUZZER 1 2.0KHz
C10 AECETK1V471B AL CHEM CAPACITOR 1 470µF/35V
C16 AECETS1C220B AL CHEM CAPACITOR 1 22µF/16V
C482 AECETS1H010B AL CHEM CAPACITOR 1 1µF/50V
C483 AECETS1HR47B AL CHEM CAPACITOR 1 0.47µF/50V
C485 AECETS1H2R2B AL CHEM CAPACITOR 1 2.2µF/16V
CX320 EFOEC8004A4 CERAMIC RESONATOR 1 8.0MHz
DISP110 L5AAAFD00019 LCD 1
DISP HOLDER F66175E40XN LCD HOLDER 1
F67525E40XN DIFFUSION SHEET 1
D40,D220-D223,D226,D227 MA2C19600E DIODE 7
IC1 MN101C54CHX L.S.I. 1
IC480 C0ABBA000230 IC 1
Q10,Q180 B1BAAJ000003 TRANSISTOR 2
D25 D4EAY271A036 ZENER RESISTOR 1 270V
RY1 AEBGJQC25F18 POWER RELAY 1
RY2 K6B1AZA00011 POWER RELAY 1
T10 G4C2AAD00006 LOW VOLTAGE TRANSFORMER 1 120V
VZ1 D3CA6103A017 VARISTOR 1
RE80 EVEJ1HF2224B REVOLVING ENCODER 1
ZD10 B0BA5R600016 ZENER DIODE 1
