10.4.3. NN-ST962S
Ref. No. Part No. Part Name & Description Pcs/Set Remarks
BZ210 L0DDEA000014 BUZZER 1 2.0KHz
C10 F2A1H471B575 AL CHEM CAPACITOR 1 470µF/50V
C11 F2A1C220B624 AL CHEM CAPACITOR 2 22µF/16V
C482 F2A1H1R0B574 AL CHEM CAPACITOR 1 1µF/50V
C483 F2A1HR47B574 AL CHEM CAPACITOR 1 0.47µF/50V
C485 F2A1H2R2B574 AL CHEM CAPACITOR 1 2.2µF/50V
DISP110 L5AYAYY00168 LCD 1
DISP HOLDER F66174U20AP LCD HOLDER 1
D10-D13 B0EAKT000025 DIODE 4
D41,D221,D223,D227,D228,D230. B0AACK000004 DIODE 6
IC1 MN69F009CA1 L.S.I. 1
IC480 C0ABBA000230 IC 1
Q10,Q180 B1AAKL000010 TRANSISTOR 2
D25 D4EAY2710001 ZENER RESISTOR 1 270V
D26,D27 D4EAY112A036 ZENER RESISTOR 2 1100V
RY1 AEBGJQC25F18 POWER RELAY 1
RY2 K6B1AZA00010 POWER RELAY 1
T10 G4C2AAD00006 LOW VOLTAGE TRANSFORMER 1 120V
ZD10 B0BA5R600016 ZENER DIODE 1
42
NN-SE992S / NN-SD982S / NN-ST962S
01/12
S-BD6
S-BD7
S-BD9
