Panasonic NN-ST962S - Digital Programmer Circuit Parts List

10.4. PARTS LIST
10.4.1. NN-SE992S
Ref. No. Part No. Part Name & Description Pcs/Set Remarks
BZ210 L0DDEA000014 BUZZER 1 2.0KHz
C10 F2A1V471B281 AL CHEM CAPACITOR 1 470µF/35V
C14 F2A1C220B624 AL CHEM CAPACITOR 1 22µF/16V
C482 F2A1H1R0B574 AL CHEM CAPACITOR 1 1µF/50V
C483 F2A1HR47B574 AL CHEM CAPACITOR 1 0.47µF/50V
C485 F2A1H2R2B574 AL CHEM CAPACITOR 1 2.2µF/50V
CX320 H2A8004A0038 CERAMIC RESONATOR 1 8.0MHz
DISP110 L5AYAYY00167 LCD 1
DISP HOLDER F66175W00AP LCD HOLDER 1
F67525E40XN DIFFUSION SHEET 1
D130 AE3294UBCA7 LED 1 BLUE LIGHT
D81-D90 B3AAB0000354 LED 10
D10-D13 B0EAKT000025 DIODE 4
D41,D220,D222,D223,D227,D229,
D230
B0AACK000004 DIODE 7
IC1 MN101E31DAZ L.S.I. 1
IC10 C0DAGYY00041 IC 1
IC80 C0ZBZ0002004 IC 1
IC380 C3EBDC000063 IC 1
IC480 C0ABBA000230 IC 1
Q10,Q180 B1BAAJ000003 TRANSISTOR 2
D26,D27 D4EAY112A036 ZENER RESISTOR 2 1100V
D32 D4EAY2710001 ZENER RESISTOR 1 270V
RY1 AEBGJQC25F18 POWER RELAY 1
RY2 K6B1AZA00010 POWER RELAY 1
T10 G4C2AAD00005 LOW VOLTAGE TRANSFORMER 1 120V
ZD10 B0BA5R600016 ZENER DIODE 1
ZD180 DZ2J15000L ZENER DIODE 1
SW1-SW11 EVQ11L05R SWITCH 11
10.4.2. NN-SD982S
Ref. No. Part No. Part Name & Description Pcs/Set Remarks
BZ210 L0DDEA000014 BUZZER 1 2.0KHz
C10 F2A1V471B281 AL CHEM CAPACITOR 1 470µF/35V
C13,C14,C16 F2A1C220B624 AL CHEM CAPACITOR 3 22µF/16V
C482 F2A1H1R0B574 AL CHEM CAPACITOR 1 1µF/50V
C483 F2A1HR47B574 AL CHEM CAPACITOR 1 0.47µF/50V
C485 F2A1H2R2B574 AL CHEM CAPACITOR 1 2.2µF/50V
CX320 H2B800400007 CERAMIC RESONATOR 1 8.0MHz
DISP110 L5AYAYY00169 LCD 1
DISP HOLDER F66177D60AP LCD HOLDER 1
D10-D13 B0EAKT000025 DIODE 4
D40,D220,D222,D223,D226,D227,
D229
B0AACK000004 DIODE 7
D480 B0JAAE000001 DIODE 1
IC1 MN101C78AAN L.S.I. 1
IC10 C0DAGYY00041 IC 1
IC350 C0EBE0000401 IC 1
IC380 C3EBDC000063 IC 1
IC480 C0ABBA000230 IC 1
Q10,Q180 B1BAAJ000003 TRANSISTOR 2
D32 D4EAY2710001 ZENER RESISTOR 1 270V
RY1 AEBGJQC25F18 POWER RELAY 1
RY2 K6B1AZA00010 POWER RELAY 1
T10 G4C2AAD00005 LOW VOLTAGE TRANSFORMER 1 120V
ZD10 B0BA5R600016 ZENER DIODE 1
ZD11 B0BA4R400002 ZENER DIODE 1
RE80 EVEJ1HF2224M REVOLVING ENCODER 1
SW1-SW2,SW6-SW14 EVQ11L05R SWITCH 11
41
NN-SE992S / NN-SD982S / NN-ST962S
