FC REFRIGE MAX NORMAL FREEZER MAX
PC "1" "2" "3"
Mean fresh food compartment
(°C) 5.0 ± 2.5 2.0 ± 2.5 1.0 ± 2.5
Mean freezer compartment
(°C) -10.0 ± 2.5 -18.5 ± 2.5 -21.0± 2.5
FC door shelf
(°C)
-
-17.0 ± 2.5
-
Vegetable case
(°C)
-
3.0 ± 2.5
-
Tray egg
(°C)
-
7.5 ± 2.5
-
PC door shelf top
(°C)
-
5.0 ± 2.5
-
Chilled case
(°C)
-
-1.0 ± 2.5
-
Running ratio
40 ± 15 55 ± 15 65 ± 15
FC REFRIGE MAX NORMAL FREEZER MAX
PC "1" "2" "3"
Mean fresh food compartment
(°C) 5.0 ± 2.5 3.0 ± 2.5 2.0 ± 2.5
Mean freezer compartment
(°C) -11.0 ± 2.5 -19.0 ± 2.5 -23.0± 2.5
FC door shelf
(°C)
-
-18.0 ± 2.5
-
Vegetable case
(°C)
-
5.0 ± 2.5
-
Tray egg
(°C)
-
7.5 ± 2.5
-
PC door shelf top
(°C)
-
5.0 ± 2.5
-
Chilled case
(°C)
-
-1.0 ± 2.5
-
Running ratio %
40 ± 15 55 ± 15 75 ± 15
FC REFRIGE MAX NORMAL FREEZER MAX
PC "1" "2" "3"
Mean fresh food compartment
(°C) 5.0 ± 2.5 3.0 ± 2.5 2.0 ± 2.5
Mean freezer compartment
(°C) -11.0 ± 2.5 -19.0 ± 2.5 -23.5 ± 2.5
FC door shelf
(°C)
-
-18.0 ± 2.5
-
Vegetable case
(°C)
-
5.0 ± 2.5
-
Tray egg
(°C)
-
7.5 ± 2.5
-
PC door shelf top
(°C)
-
5.0 ± 2.5
-
Chilled case
(°C)
-
0.5 ± 2.5
-
Running ratio
40 ± 15 55 ± 15 85 ± 15
Control setting
Control setting
Control setting
4.1 NR- BK266 SERIES
4.3 NR- BK346 SERIES
4.2 NR- BK306 SERIES
Under no-load condition and ambient temperature at 32°C ± 1°C
Under no-load condition and ambient temperature at 32°C ± 1°C
Under no-load condition and ambient temperature at 32°C ± 1°C
- 8 -
