7
TEMPERATURE CONTROL
Refrigerator compartment temperature control
The temperature can be adjusted for 1 - 3 levels.
Indicating number and cool level.
“MIN” Higher by approx. 5°C ~ 10°C
“MED” Approx. 2°C ~ 7°C
“MAX” Lower by approx. -1°C ~ 4°C
“MAX” Lower by approx. -19°C ~ -24°C
Approx. -17°C ~ -22°C
“MIN” Higher by approx. -13°C ~ -18°C
Freezer compartment temperature control
Remark
While operating the refrigerator for the fi rst time, after connecting the plug, adjust the
temperature to “MIDDLE” position of each control and leave it for 24 hours for the
effective cooling operation. After that, adjust the temperature as you prefer. If you want to
save the energy, do not adjust the temperature lower than the actual operating condition.
The temperature can be adjusted for
MIN - MAX levels. Indicating operate and
cool level.
