Panasonic NV-DA1 - Page 10

No. Item / Part Fig. Removal (Screw &
Other)
(1) Front Case
Unit
Fig.1 4-Screws (A)
Fig.2-1 Open the DV Terminal
Cover.
1-Screw (B)
3-Screws (C)
Fig.2-2 Unlock----Locking
Tabs.
Disconnect FP6401
(2) Rear Case
Unit &
Cassette
Cover Unit
Fig.3-1 4-Screws (D/E)
Fig.3-2 Disconnect FP6701
1-Screw (F)
Unlock----Locking
Tabs for Screw
2-Screws (G)
3-Screws (H/I/J)
(3) Speaker Amp
C.B.A. & Side
Case (L) Unit
Fig.3-3 Remove the Side Case
(L) Unit.
3-Screws (K)
2-Screws (L)
Disconnect the
following Connectors.
P3001, FP4802, FP4901
Remove the Speaker
Amp C.B.A.
(4) Mecha. Unit Fig.3-3 2-Screws (M/N)
Fig.3-4 Disconnect----PP2001/
FP3201
Remove the Mecha.
Unit.
10
