Panasonic NV-DA1 - Page 107

Ref. No. Part No. Part Name &
Description
Pcs Remarks
VEP01830A RS232C C.B.A. (RTL)
B1201 VL2020/1HF LITHIUM BATTERY 1
C1202 ECST1VX335Z T.CAPACITOR CH
35V 3.3U
1
C1203 ECST1VX335Z T.CAPACITOR CH
35V 3.3U
1
C1204 ECST1DY335Z T.CAPACITOR CH
20V 3.3U
1
C1205
ECUX1H102KBV
C.CAPACITOR CH
50V 1000P
1
C1206
ECUX1C104KBV
C.CAPACITOR CH
16V 0.1U
1
C1207 ECST1DY335Z T.CAPACITOR CH
20V 3.3U
1
C1208 ECST1VX335Z T.CAPACITOR CH
35V 3.3U
1
C1209
ECUX1C104KBV
C.CAPACITOR CH
16V 0.1U
1
C1210 ECST0JY226Z T.CAPACITOR CH
6.3V 22U
1
D1201 MA3062 DIODE 1
D1202 MA2S728 DIODE 1
FL1201 VLF1376A256 FILTER 1
FL1202 VLF1394 FILTER 1
FL1203 VLF1378 FILTER 1
FP1202 VJS4018B014 CONNECTOR
(FEMALE) 14P
1
IC1201 UPD4721GS IC 1
IP1201 VSF0233F31 FUSE 1
JK1201 VEJ1839 JACK BOARD 1
L1201 VLQ0807K100 COIL 10UH 1
LB1201 VLP0307 COIL 1
LB1202 VLP0307 COIL 1
P1201 VJP3904C012 CONNECTOR
(MALE) 12P
1
PS1201 VJS3320B010 CONNECTOR
(FEMALE) 10P
1
R1202 ERJ3GEYJ101 M.RESISTOR CH 1/
16W 100
1
R1203 ERJ3GEYG822 M.RESISTOR CH 1/
16W 8.2K
1
R1204 ERJ3GEYJ563 M.RESISTOR CH 1/
16W
56K
1
107
