Panasonic NV-DA1 - Page 108

16W 56K
Ref. No. Part No. Part Name &
Description
Pcs Remarks
R1205 ERJ3GEYJ101 M.RESISTOR CH 1/
16W 100
1
R1206 ERJ3GEYJ101 M.RESISTOR CH 1/
16W 100
1
R1207 ERJ3GEYJ101 M.RESISTOR CH 1/
16W 100
1
R1208 ERJ3GEYG102 M.RESISTOR CH 1/
16W 1K
1
R1213 ERJ3GEYJ680 M.RESISTOR CH 1/
16W 68
1
R1214 ERJ3GEYJ680 M.RESISTOR CH 1/
16W 68
1
R1215 ERJ3GEYJ181 M.RESISTOR CH 1/
16W 180
1
R1221 ERJ6GEY0R00 M.RESISTOR CH 1/
10W 0
1
R1222 ERJ6GEY0R00 M.RESISTOR CH 1/
10W 0
1
MISCELLANEOUS
VEE0D94 WIRE CABLE 1
12.2.13. MENU OPERATION C.B.A.
Ref. No. Part No. Part Name &
Description
Pcs Remarks
VEP06C66A MENU OPERATION
C.B.A.
(RTL)
FP6803 VJS3319B006 CONNECTOR
(FEMALE) 6P
1
S6901 VSR0235 SWITCH 1
12.2.14. MF RING U.
Ref. No. Part No. Part Name &
Description
Pcs Remarks
VXP1896 MF RING U. (RTL)
PC710
CNA1312K01VT
PHOTO SENSOR 1
PC711
CNA1312K01VT
PHOTO SENSOR 1
MISCELLANEOUS
XQN16+CJ5 SCREW 3
12.2.15. FRONT C.B.A.
108
