Panasonic NV-DA1 - Page 109

Ref. No. Part No. Part Name &
Description
Pcs Remarks
VEP06C64A FRONT C.B.A. (RTL)
C6401
ECUM1E104KBN
C.CAPACITOR CH
25V 0.1U
1
C6402 ECST0JY106Z T.CAPACITOR CH
6.3V 10U
1
C6403
ECUX1H103KBV
C.CAPACITOR CH
50V 0.01U
1
D6401 PH310 DIODE 1
D6402 CL150UR DIODE 1
D6403 MA8056 DIODE 1
FP6401 VJS3452A012 CONNECTOR
(FEMALE) 12P
1
FP6402 VJP3172D004 CONNECTOR
(MALE) 4P
1
IR6401 VEK8283 IR RECEIVER UNIT 1
L6401 VLQ0807K100 COIL 10UH 1
S6401 EVQPA501K PUSH SWITCH 1
S6402 EVQPA501K PUSH SWITCH 1
12.2.16. REAR OPERATION C.B.A.
Ref. No. Part No. Part Name &
Description
Pcs Remarks
VEP06C65A REAR OPERATION
C.B.A.
(RTL)
D6701 CL150YG-CD DIODE 1
D6702 CL150UR DIODE 1
FP6701 VJS3452A014 CONNECTOR
(FEMALE) 14P
1
FP6702 VJS3319B005 CONNECTOR
(FEMALE) 5P
1
S6701 ESE103119 SWITCH 1
S6702 VMG0763 RUBBER SWITCH 1
S6703 EVQPA501K PUSH SWITCH 1
S6704 ESD165236 SWITCH 1
12.2.17. MIC UNIT
109
