Panasonic NV-DA1 - Page 110

Ref. No. Part No. Part Name &
Description
Remarks
VEK8596 MIC UNIT (RTL)
C4801
ECUX1E223KBV
C.CAPACITOR CH
25V 0.022U
1
C4802
ECUX1C473KBV
C.CAPACITOR CH
16V 0.047U
1
C4803
ECUM1E823KBN
C.CAPACITOR CH
25V 0.082U
1
C4804
ECUX1H181JCV
C.CAPACITOR CH
50V 180P
1
C4805
ECUM1C154KBN
C.CAPACITOR CH
16V 0.15U
1
C4806
ECUX1E223KBV
C.CAPACITOR CH
25V 0.022U
1
C4807
ECUX1C473KBV
C.CAPACITOR CH
16V 0.047U
1
C4808
ECUX1H181JCV
C.CAPACITOR CH
50V 180P
1
C4809
ECUM1C154KBN
C.CAPACITOR CH
16V 0.15U
1
C4810
ECUM1E823KBN
C.CAPACITOR CH
25V 0.082U
1
C4814
ECUX1E223KBV
C.CAPACITOR CH
25V 0.022U
1
C4816
ECUX1E223KBV
C.CAPACITOR CH
25V 0.022U
1
C4817 ECST0JX226Z T.CAPACITOR CH
6.3V 22U
1
C4830 ECST0JX226Z T.CAPACITOR CH
6.3V 22U
1
FP4802 VJS3319B006 CONNECTOR
(FEMALE) 6P
1
FP4803 VJS3320B005 CONNECTOR
(FEMALE) 5P
1
IC4801 NJM2112V IC 1
Q4805 2SD1819A TRANSISTOR 1
Q4810 2SD1819A TRANSISTOR 1
Q4811 2SD1819A TRANSISTOR 1
R4801 ERJ6GEYG392 M.RESISTOR CH 1/
10W 3.9K
1
R4802 ERJ6GEYG392 M.RESISTOR CH 1/
10W 3.9K
1
R4803 ERJ6GEYG392 M.RESISTOR CH 1/
10W 3.9K
1
R4804 ERJ6GEYG392 M.RESISTOR CH 1/
10W 3.9K
1
R4805 ERJ3GEYJ273 M.RESISTOR CH 1/
16W 27K
1
R4806 ERJ3GEYJ473 M.RESISTOR CH 1/
16W 47K
1
R4807 ERJ3GEYJ183 M.RESISTOR CH 1/
16W 18K
1
