Panasonic NV-DA1 - Page 155

( )
4.8 2.3 1.6 1.6
2.3
1.6 1.6
TO VTR MAIN CONNECTION
<TO SPK AMP>
A RCH OUT
A LCH OUT
DA OUT R
DA OUT L
REG 5V
D GND
TO VTR MAIN CONNECTION
<TO VIDEO1>
TO VTR MAIN CONNECTION
<TO POWER>
-
+
+
-
8765
4321
IC4001
NJM3414AV
R4001
22K
R4002
10K
C4001
120P
C4005
1500P
R4006
10K
C4006
1500P
C4018
6V10
R4018
51K
C4012
6V10
C4011
0.1
R4017
100K
L4001
10µ
R4005
22K
C4002
120P
NOTE:THE MEASUREMENT MODE OF THE DC VOLTAGE IN THE BRACKETS ON THIS DIAGRAM IS RECORD MODE.(SP MODE)
THE MEASUREMENT MODE OF THE DC VOLTAGE OUT OF THE BRACKETS ON THIS DIAGRAM IS PLAYBACK MODE.
NOTE:DO NOT USE ANY PART NUMBER SHOWN ON THIS SCHEMATIC DIAGRAM FOR ORDERING.
WHEN YOU ORDER A PART,PLEASE REFER TO PARTS LIST.
123
A
B
4
C
AUDIO MAIN SIGNAL PATH IN REC MODE
AUDIO MAIN SIGNAL PATH IN PLAYBACK MODE
R4004
6800
283
282
R4003
6800
285
284
280
281
TO VTR MAIN CONNECTION
