46 (1) VGK2401 TALLY MOUNT 1
Ref. No. Part No. Part Name &
Description
Pcs Remarks
47 (1) VGL0805 TALLY PANEL 1
48 (1) VGQ2759 CABLE SHEET 1
49 (1) VGQ4820 DV COVER HINGE 1
50 (1) VGU7929 CAMERA
OPERATION
BUTTON
1
51 (1) VKF2970 DV COVER 1
52 (1) VKW2542 SENSOR WINDOW 1
53 (1) VYF2523 LENS HOOD U. 1
54 (1) VYK8587 FRONT CASE (1) U. 1
55 (1) VYF2524 HOOD CAP U. 1
56 (1) VYQ1606 MIC NET U. 1
57 (1) VGQ4625 SHOE COVER 1
58 (1) VGU7943 TOP OPERATION
BUTTON
1
59 (1) VKM5029 TOP CASE 1
60 (1) VMC1372 SHOE SPRING 1
61 (1) VMP5490 SHOE 1
62 (1) VMP5807 SHOE ANGLE 1
63 (1) VYQ1607 LENS FRAME U. 1
64 (1) VMG0952 PROTECT RUBBER 2
B1 (1) XQN16+
BJ4FZ
SCREW 3
B2 (1) XQN2+BJ3 SCREW 1
B3 (1) VHD1127 SCREW 4
B4 (1) XQN16+CJ4 SCREW 2
B6 (1) XQN2+CJ6FZ SCREW 2
B7 (1) XQN16+
BJ4FN
SCREW 3
B8 (1) XQN16+B3FZ SCREW 5
B9 (1) XQN16+
BJ5FZ
SCREW 3
B10 (1) XQN16+B4FN SCREW 4
B11 (1) XQN2+CJ3 SCREW 3
B12 (1) XQN2+CJ4 SCREW 3
B13 (1) XQN2+CJ6 SCREW 1
B14 (1) XQN2+C25 SCREW 2
B15 (1) XQN2+
BJ35FZ
SCREW 5
B16 (1) XQN16+BF3 SCREW 4
B17 (1) XQN16+BJ4 SCREW 1
B18 (1) XQN2+A3FN SCREW 1
B19 (1) XQS2+A10FN SCREW 4
B20 (1) XQN2+BF5 SCREW 2
B21 (1) XQN16+
BJ6FN
SCREW 1
B22 (1) XQN16+B3FN SCREW 3
B23 (1) XQN16+B6FN SCREW 1
B24 (1) VHD1132 SCREW 2
B26 (1) XQN2+CJ4 SCREW 2
