12.1.2. FRAME & CASING PARTS SECTION (2)
Ref. No. Part No. Part Name &
Description
Pcs Remarks
101 (2) VGP4575 SCREW CAP 2
102 (2) VGQ5005 MECHA. FIXING
PIECE
1
103 (2) VMZ2708 BER BARRIER 1
104 (2) VXA5933 MECHA. FIXING
ANGLE U.
1
105 (2) VEK8533 DEW SENSOR 1
106 (2) VGL0806 VTR CHANGE
PANEL
1
107 (2) VGQ2839 CABLE SHEET 1
108 (2) VGQ4272 S/S BUTTON PIECE 1
109 (2) VGQ4493 EJECT BUTTON
HOLDER
1
110 (2) VGQ4494 S/S LEVER 1
111 (2) VGQ5012 PHOTO SHOT
BUTTON HOLDER
1
112 (2) VGQ5145 BUTTON SPACER 1
113 (2) VGU7575 EJECT BUTTON 1
114 (2) VGU7577 S/S BUTTON 1
115 (2) VGU7933 VTR CHANGE
BUTTON
1
116 (2) VGU7934 PHOTO SHOT
BUTTON
1
117 (2) VKM5030 REAR CASE 1
118 (2) VMC1470 S/S CLICK SPRING 1
119 (2) VMP5748 DEW FIXING
ANGLE
1
120 (2) VSC4816 REAR PLATE 1
121 (2) VEK8565 ZOOM OPERATION
U.
1
122 (2) VGQ5006 MECHA. ADJUST
PIECE
1
123 (2) VMA0A33 GRIP ANGLE 1
124 (2) VYC0802 GRIP BELT U. 1
125 (2) VYK8590 SIDE CASE (L) 1 U. 1
126 (2) VKF2965 JACK COVER 1
127 (2) VYK8743 CASSETTE COVER
(1) U.
1
127-1(2) VMB3148 CASSETTE COVER
SPRING
1
127-2(2) VMP5413 CASSETTE FIXING
BASE
1
128 (2) VMZ2839 BARRIER 1
B101 (2) VHD0866 SCREW 3
B102 (2) VHD1214 SCREW 3
B103 (2) XQN16+BJ5 SCREW 2
B104 (2) XQN16+B15 SCREW 1
B105 (2) XQN2+BJ4 SCREW 6
B106 (2) VHD0794 SCREW 1
B107 (2) XQN16+B4 SCREW 1
B108 (2) VHD1105 SCREW 1
