Panasonic NV-DA1 - 12.1.3. LCD Parts Section; 12.1.4. Camera Lens Section

Ref. No. Part No. Part Name &
Description
Pcs Remarks
B109 (2) XQN16+B6FZ SCREW 1
B110 (2) XQN16+
CJ8FZ
SCREW 2
B111 (2) XQN2+B4 SCREW 3
B112 (2) XQN16+
BJ6FZ
SCREW 4
B113 (2) XQN16+
BJ5FZ
SCREW 1
B114 (2) VHD1100 SCREW 2
B115 (2) XQN16+B3FZ SCREW 2
B116 (2) VMS5604 SCREW 2
12.1.3. LCD PARTS SECTION
Ref. No. Part No. Part Name &
Description
Pcs Remarks
201 (3)
C0D25T2021VB
LCD PANEL 1
202 (3) VEK8501 BACK LIGHT U. 1
203 (3) VGQ2759 PROTECT SHEET 1
204 (3) VGQ2184 PROTECT SHEET 1
205 (3) VGQ4758 PROTECT SHEET 2
206 (3) VGQ5136 FLEX. CARD
FIXING PIECE
1
207 (3) VKM5024 LCD BOTTOM
CASE
1
208 (3) VGQ5002 HINGE TOP COVER 1
209 (3) VGQ5064 HINGE BOTTOM
COVER
1
210 (3) VXD0292 LCD ROTARY
HINGE (1) U.
1
212 (3) VYK8592 LCD TOP CASE U. 1 NV-DA1EG/B
212 (3) VYK8734 LCD TOP CASE U. 1 NV-DA1EN/ENA
213 (3) VMB3274 LOCK PIECE
SPRING
1
214 (3) VMP5747 LOCK PIECE
PLATE
1
B201 (3) XQN16+B2FZ SCREW 2
B202 (3) XQN2+BF35 SCREW 2
B203 (3) XQS16+AJ3 SCREW 2
B204 (3) XQN16+
BF3FN
SCREW 1
B205 (3) XQN16+B3FN SCREW 4
12.1.4. CAMERA LENS SECTION
40
