Panasonic NV-DA1 - 12.1.5. VCR Mechanism Section (1)

Ref. No. Part No. Part Name &
Description
Pcs Remarks
301 (4) VDL0421 CRYSTAL FILTER 1
302 (4) VEK8489 CCD UNIT 1
303 (4) VMX2376 CCD CUSHION 1
304 (4) VXW0418 LENS UNIT 1
304-1 (4) VEK8084 LENS FLEX. 1
304-2 (4) VEM0626 FOCUS MOTOR U. 1
304-3 (4) VEM0662 ZOOM MOTOR U 1
304-5 (4) VMS5735 Z GUIDE POLE 2
304-6 (4) VMS5736 F GUIDE POLE 2
304-7 (4) VXL2445 IRIS UNIT 1
304-8 (4) VXP1807 2ND MOVING
FRAME U.
1
304-9 (4) VXP1818 4TH MOVING
FRAME U.
1
304-
10(4)
VXQ0642 MAIN FRAME U. 1
304-
11(4)
VXQ0643 3RD LENS FRAME
U.
1
304-
12(4)
VDW0490 CRYSTAL MOUNT
PLATE
1
B301 (4) VHD0852 SCREW 1
B302 (4) XQN16+CJ5 SCREW 16
B303 (4) XQN16+CJ6 SCREW 2
12.1.5. VCR MECHANISM SECTION (1)
41
