Panasonic NV-DA1 - 12.1.6. VCR Mechanism Section (2)

Ref. No. Part No. Part Name &
Description
Pcs Remarks
401 (5) VEG1438 CYLINDER UNIT 1
402 (5) VEM0624 CAPSTAN MOTOR
UNIT
1
403 (5) VEP05352A HEAD AMP C.B.A. 1
403-*(5) VSC4639 HEAD AMP SHIELD
CASE
1
404 (5) VES0856 FLEXIBLE CABLE 1
405 (5) VMA9708 CAPSTAN COVER 1
406 (5) VMA9179 RADON PLATE 1
407 (5) VMD2373 RAIL 1
408 (5) VSC4640 SHIELD CASE 1
409 (5) VSR0114 MODE SW 1
410 (5) VXA5407 CAM GEAR UNIT 1
411 (5) VXA5409 S BOAT UNIT 1
412 (5) VXA5410 T BOAT UNIT 1
413 (5) VXA5417 GEAR BOX
(LOADING MOTOR)
1
414 (5) VXA5612 RADON COVER
UNIT
1
415 (5) VXL2461 T2 ARM UNIT 1
415-1(5) VMB2789 T2 ARM SPRING 1
416 (5) VXL2468 CLEANING ARM
UNIT
1
416-1(5) VMB2791 CLEANING ARM
SPRING
1
Ref. No. Part No. Part Name &
Description
Pcs Remarks
417 (5) VXL2470 S1 ARM UNIT 1
418 (5) VXL2471 T1 ARM UNIT 1
419 (5) VMA9753 BRUSH ARM
STOPPER
1
420 (5) VMB2777 CAPSTAN ADJ.
SPRING
1
421 (5) VXA5387 GARAGE UNIT 1
B401 (5) VHD0878 SCREW 1
B402 (5) VHD0989 SCREW 2
B403 (5) XQN14+B4 SCREW 2
B404 (5) XQN14+B2 SCREW 3
B405 (5) XQN14+B35 SCREW 2
B406 (5) XQN14+BQ4 SCREW 2
B407 (5) XQN14+B15 SCREW 9
B408 (5) XQN14+B2 SCREW 2
B409 (5) VHD0882 SCREW 6
B410 (5) XQN14+B4FZ SCREW 1
W401 (5) VMX2027 WASHER 2
12.1.6. VCR MECHANISM SECTION (2)
42
