Panasonic NV-DA1 - Page 43

Ref. No. Part No. Part Name &
Description
Pcs Remarks
451 (6) VDG1030 DRIVE PULLEY 1
452 (6) VDG1031 CENTER PULLEY 1
453 (6) VDG1032 SENSOR GEAR 1
454 (6) VDV0265 TIMING BELT 1
455 (6) VMA9178 PINCH PRESSURE
PLATE
1
457 (6) VMA9181 BRAKE ROD
SUPPORT (T)
1
458 (6) VMB2776 SPRING 1
459 (6) VSH0067 MIC SWITCH 1
460 (6) VSJ0114 SOLENOID 1
461 (6) VXA5401 BRAKE ROD UNIT 1
462 (6) VXA5408 T3 ROD UNIT 1
463 (6) VXA5411 LED HOLDER UNIT 1
464 (6) VXA5412 COVER PLATE
UNIT
1
465 (6) VXL2454 P IDLER ARM UNIT 1
466 (6) VXL2455 FR IDLER ARM
UNIT
1
467 (6) VXL2456 TENSION ARM
UNIT
1
468 (6) VXL2732 PAD ARM UNIT 1
468-1(6) VMB2788 TENSION SPRING 1
468-2(6) VMB2787 PAD ARM SPRING 1
469 (6) VXL2462 T3 ARM UNIT 1
470 (6) VXL2464 PINCH ARM UNIT 1
471 (6) VXL2466 EJECT ARM UNIT 1
472 (6) VXR0347 SUPPLY REEL
TABLE
1
473 (6) VXR0348 TAKE UP REEL
TABLE
1
474 (6) VXZ0319 TAKE UP MAIN
BRAKE
1
474-1(6) VMB2782 T MAIN BRAKE
SPRING
1
475 (6) VXZ0321 SUPPLY MAIN
BRAKE
1
475-1(6) VMB2783 S MAIN BRAKE
SPRING
1
476 (6) VXZ0322 FF BRAKE UNIT 1
476-1(6) VMB2784 FF BRAKE SPRING 1
477 (6) VXZ0323 REV BRAKE UNIT 1
477-1(6) VMB2786 REV SPRING 1
477-2(6) VMB2785 REV BRAKE
SPRING
1
B451 (6) VHD0884 SCREW 1
B452 (6) XQN14+B15 SCREW 2
B453 (6) VHD0883 SCREW 5
B454 (6) XQN14+B35 SCREW 3
W451 (6) VMX2503 WASHER 1
W452 (6) VMX2400 WASHER 1
W453 (6) VMX2504 WASHER 1
W454
(
6)
VMX2027
WASHER
1
43
