Ref. No. Part No. Part Name &
Description
Pcs Remarks
VEP22280A CCD FLEX. CARD
C.B.A.
(RTL)
C292 ECST1VX225Z T.CAPACITOR CH
35V 2.2U
1
C293
ECUM1H473KBN
C.CAPACITOR CH
50V 0.047U
1
C294
ECUM1H473KBN
C.CAPACITOR CH
50V 0.047U
1
C295
ECUM1E104ZFN
C.CAPACITOR CH
25V 0.1U
1
D291 MA143 DIODE 1
PS291 VJP4009C020 CONNECTOR
(MALE) 20P
1
Q291 2SC3930 TRANSISTOR 1
R291 ERJ6GEYG560 M.RESISTOR CH 1/
10W 56
1
R292 ERJ6GEYF472 M.RESISTOR CH 1/
10W 4.7K
1
MISCELLANEOUS
VJB22280 FLEX. CARD 1
12.2.4. LENS FLEX. CARD C.B.A.
Ref. No. Part No. Part Name &
Description
Pcs Remarks
VEK8084 LENS FLEX. CARD
C.B.A.
(RTL)
MISCELLANEOUS
0N1004-R PHOTO
INTERRUPTER
1
12.2.5. E.V.F. (A) C.B.A.
