Panasonic NV-DA1 - Page 76

Ref. No. Part No. Part Name &
Description
Pcs Remarks
VEP28240D E.V.F.(A) C.B.A. (RTL)
BL881 VLL0204 FLUORESCENT
LAMP
1
Q881 2SK1299-3S TRANSISTOR 1
R881 ERJ3GEYJ473 M.RESISTOR CH 1/
16W 47K
1
T881 ETJ09K31AM TRANSFORMER 1
MISCELLANEOUS
VWJ1174 FLAT CARD CABLE 1
12.2.6. E.V.F. (B) C.B.A.
Ref. No. Part No. Part Name &
Description
Pcs Remarks
VEP28244C E.V.F.(B) C.B.A. (RTL)
C801 ECUM1A335KB C.CAPACITOR CH
10V 3.3U
1
C802 ECGC1BB150 E.CAPACITOR CH
12.5V 15U
1
C827
ECUX1H102KBV
C.CAPACITOR CH
50V 1000P
1
C829
ECUX1C104KBV
C.CAPACITOR CH
16V 0.1U
1
C830
ECUX1H470JCV
C.CAPACITOR CH
50V 47P
1
C832
ECUX1H472KBV
C.CAPACITOR CH
50V 4700P
1
C833 ECST1CY225Z T.CAPACITOR CH
16V 2.2U
1
C834
ECUX1C104KBV
C.CAPACITOR CH
16V 0.1U
1
C835
ECUX1C104KBV
C.CAPACITOR CH
16V 0.1U
1
C836
ECUX1C104KBV
C.CAPACITOR CH
16V 0.1U
1
C837
ECUX1C104KBV
C.CAPACITOR CH
16V 0.1U
1
C838 ECST0JY106Z T.CAPACITOR CH
6.3V 10U
1
C839 ECST0JY106Z T.CAPACITOR CH
6.3V 10U
1
C865
ECUX1C104KBV
C.CAPACITOR CH
16V 0.1U
1
C866
ECUX1C104KBV
C.CAPACITOR CH
16V 0.1U
1
D801 MA338 DIODE 1
D803 1SS355 DIODE 1
