Panasonic NV-DA1 - Page 77

Ref. No. Part No. Part Name &
Description
Pcs Remarks
FP801 VJS3319B018 CONNECTOR
(FEMALE) 18P
1
FP802 VJS3319B016 CONNECTOR
(FEMALE) 16P
1
IC802 ET2070F0C IC 1
IC805 TA75S558F IC 1
L801 VLQ0426J6R8 COIL 6.8UH 1
L803 VLQ0807K100 COIL 10UH 1
L804 VLQ0807K100 COIL 10UH 1
L805 VLQ0807K100 COIL 10UH 1
L881 VLQ0779K100 COIL 10UH 1
R802 ERJ3GEYG102 M.RESISTOR CH 1/
16W 1K
1
R805 ERJ3GEYG102 M.RESISTOR CH 1/
16W 1K
1
R807 ERJ3GEYG102 M.RESISTOR CH 1/
16W 1K
1
R808 ERJ3GEYG102 M.RESISTOR CH 1/
16W 1K
1
R832 ERJ3GEYJ104 M.RESISTOR CH 1/
16W 100K
1
R834 ERJ3GEYG102 M.RESISTOR CH 1/
16W 1K
1
R835 ERJ3GEYG472 M.RESISTOR CH 1/
16W 4.7K
1
R836 ERJ3GEYG471 M.RESISTOR CH 1/
16W 470
1
R841 ERJ3GEYJ101 M.RESISTOR CH 1/
16W 100
1
R849 ERJ3GEYG471 M.RESISTOR CH 1/
16W 470
1
R850 ERJ3GEYJ223 M.RESISTOR CH 1/
16W 22K
1
R851 ERJ3GEYJ103 M.RESISTOR CH 1/
16W 10K
1
R852 ERJ3GEYG682 M.RESISTOR CH 1/
16W 6.8K
1
R878 ERJ3RBD183 M.RESISTOR CH 1/
16W 18K
1
R879 ERJ3RBD183 M.RESISTOR CH 1/
16W 18K
1
R880 ERJ3RBD332 M.RESISTOR CH 1/
16W 3.3K
1
12.2.7. SUB C.B.A.
77
