14
Attaching the Shoulder Strap
We recommend that you attach the Shoulder Strap before going
out of doors to record so as to avoid dropping the Movie
Camera.
1 Pull the end of the Shoulder Strap through the
Shoulder Strap Holder on the Movie Camera.
2 Fold the tip of the Shoulder Strap, run it through
the Shoulder Strap Length Adjuster, and pull it.
≥When attaching the Shoulder Strap to another side of the
Shoulder Strap Holder, you need to pull out the viewfinder
and tilt it up.
≥Pull it out more than 2 cm
1 from the Shoulder Strap
Length Adjuster so that it cannot slip off.
~~~~~~~~~~~~~~~~~~~~~
Inserting a Cassette
When power is supplied to the Movie Camera, the Cassette can
be taken out without turning the Movie Camera [ON].
1 Slide the [TAPE EJECT] Lever to open the Cover.
2 Insert a Cassette.
3 Close the Cover and press the [PUSH CLOSE]
mark to lock the Cover.
ª Accidental Erasure Prevention
Opening the accidental erasure prevention slider 1 on the
cassette (by sliding it in the [SAVE] arrow direction) prevents
recording. To enable recording, close the accidental erasure
prevention slider (by sliding it in the [REC] arrow direction).
≥For other notes concerning this item, see page 48.
~~~~~~~~~~~~~~~~~~~~~
Turning on the Movie Camera and
Selecting Modes
1 Set the [VCR/OFF/CAMERA/M-CARD] Switch to
[CAMERA], [VCR] or [M-CARD].
([M-CARD]: NV-DS65 only)
≥The [POWER] Lamp lights up.
CAMERA: Camera Mode
VCR: VCR Mode
M-CARD: Card Recording Mode
Card Playback Mode (To this mode, press the
[M-PLAY] Button in the Card Recording Mode)
To Turn off the Power
Set the [VCR/OFF/CAMERA/M-CARD] Switch to [OFF].
R E C
SAVE
2
3
1
TAPE
EJECT
PUSH CLOSE
1
2
1
1
1
M-CARD
CAMERA
OFF
VCR
