Before Use
-7-
Controls and Components
ª Movie Camera
(1) LCD Monitor Open Knob [OPEN4] -14-
(2)
LCD Monitor -14-, -56-
(3)
Card Slot Cover Open Lever [OPEN]
(NV-GS15 only)
-13-
(4)
Card Slot (NV-GS15 only) -13-
(5)
Card Slot Cover (NV-GS15 only) -13-
(6)
Recording Check Button [S] -21-
Recording Button [REC]
(Available only with NV-GS15)
-43-
Due to limitations in LCD production
technology, there may be some tiny bright or
dark spots on the LCD Monitor screen.
However, this is not a malfunction and does
not affect the recorded picture.
RESET
RESET
REC
REVIEW
(1) (2) (3)
(7)
(8) (9) (10)
(15)(16)(17)(18)(19)
(6)
(12)
(20)
(4) (5)
NV-GS15
(11)
(13)
(14)
(3)
NV-GS8/NV-GS11
(21)
(7)
(8) (9) (10)
(12)
(20)
(11)
(13)
(21)
(15)(16)(17)(18)(19)
(6)
(7)
Colour Night View Button
[COLOUR NIGHT VIEW]
-25-
(8)
Soft Skin Button [SOFT SKIN] -26-
(9)
Reset Button [RESET] -48-, -59-
(10)
Multi Button [MULTI] -30-, -36-
Picture-in-Picture Button [P-IN-P] -31-
(11)
Speaker -32-
(12)
Backlight Button [BACK LIGHT] -25-
(13)
Light Button [LIGHT] -22-
(14)
Card Access Lamp (NV-GS15 only) -13-
(15)
Pause Button [;] -33-,
Still Button [STILL]
-21-
(16)
Fast Forward/Cue Button [5] -32-, -36-
(17)
Play Button [1] -32-, -36-
Enter Button [ENTER] -15-
(18)
Stop Button [∫] -32-, -36-
Fade Button [FADE] -25-
(19)
Rewind/Review Button [6] -32-, -36-
(20)
Menu Button [MENU] -15-
(21)
Mode Selector Switch
[AUTO/MANUAL/FOCUS]
-20-, -26-
(22)
Lens Hood -57-
(23)
Lens
(24) Microphone (built-in, stereo) -24-, -26-
(25)
Eyecup
(26) Cassette Holder
(27) Cassette Compartment Cover -13-
(28)
USB Socket [ ] -44-
(22)
(23)
(24)
(25)
MIC
PHONES/
REMOTE
A/V OUT
(26)
(32) (33)
(29)(28)
(27)
(31)
(30)
