No.
Item/Part Fig. Removal (Screw& Other)
4. EVF/ Rear
Case Unit
Fig. 9 1-Screw (M)
Fig.
10
4-Screws (N/W)
Disconnect the following
connectors.
FP3401/FP603/FP1002
Remove the EVF/Rear Case
Unit.
5. VTR Main
C.B.A&
Mecha.
Fig.
11
1-Screw (O)
Disconnect the FP4001/
FP2205
Fig.
12
Cassette Cover Open
Unlock the Lock Release
Lever.
Fig.
11
Remove the Mecha. with
VTR
Main C.B.A..
6. VTR Main
C.B.A
Fig.
13
Disconnect the following
connectors.
FP5001/FP2202/FP2203/
FP2201/
FP2204
Unlocks - (a)
3-Screws (P)
Remove the Mecha. Frame.
7. Mic Unit Fig.
14
2-Screws (Q)
Disconnect the FP4902.
Remove the Mic Unit.
4-Screws (R)
Remove the Focus Ring.
8. Monitor
C.B.A.
Fig.
15
4-Screws (S/T)
Remove the LCD Case
(Upper) Unit.
1-Screw (U)
Disconnect the following
connectors.
FP901/FP903/FP904/FP905
Unsolder read wire.
Removethe Hall Sensor Flex.
/Monitor
C.B.A./
Back Light Unit.
