Panasonic OLED-201806 - Page 37

IC7405
( TNPA6376** )
IC7301
1
Start Vcc
15
11
T7301
Q7301
Q7302
10
Q7202
PC7302
L=ON
D7104,
7105
R7104-
7105
16V
4
PC7301
feedback
2
3
STB5V
PC7303
IC7401
EN
VH
VCC
HO
LO
FB
64V(*)
Q7402/04
Q7401
P3
7
9
16V
P2
SUB-ON
VCC
Standby/ON
Switch
D7106
Rectifier
PFC
IC7201
Q7201
T7202
D7217
C7213/15
8
7
VCC
1 - 4
Q7403/05
BL-ON
L7815
37
Anode2
Cathode2
Vcc
( PFC = ON
AC100V: 380V
AC240V: 380V)
SRV-16V
SRV-VLED
SRV-VLED2
SRV-5V
(*)The DC level is different by the LCD panel.
Q7804
Tr
3
STB
PWM
9
PGS
D7406/07
C7424
D7403
C7422
13
14
L7816
Anode1
SRV-VLED1
Q7801
Cathode1
Tr
1
5
3
7
Start up Operation-6
< from to : P/LD board >
2
3
LED
Drive
IC7800
P
Ex. 55FX600** series
Q7414
Q7416
/17
Q7315
<A+P>
