Panasonic OLED-201806 - Page 57

PA7801-PA7808
Q7801Q7802Q7803Q7804
Q7805Q7806Q7807Q7808
1: Emitter
(4: base)
Collector
SRV-VLED
P2 connector
Q7804 Q7805
Q7806
Q7807
Q7808
Q7809
Q7810
Q7811
E:emitter
C:collector
55inch P board (TNPA6704**) 65inch P board (TNPA6710**)
Troubleshooting for LED Blinking ( 1 time blink ) for A+P type -6
<A+P>
A+P Board Type ( only TX-65/55FX74#/75#/78#, TH/TC-65/55FX800)
PA7801-PA7808
SRV-VLED
