_J
For ANTJCable -_ VCR -_ TV
Connect cable from
Antenna/Cable to VCR's IN
FROM ANT. jack.
Connect VCR's OUT TO TV
jack to TV's ANT. IN jack
with included RF Cable
accessory.
VCR iN FROM ANT.
TV
(1_INf,om
ANT fCABLE
OUT TO TV
VHF/UHF
For DSS/Cable Box _ VCR + TV
Connect your cable box's
OUT jack to the VCR's IN
FROM ANT. jack with an RF
cable.
Connect VCR's OUT TO TV
jack to TV's ANT. IN jack
with included RF Cable
accessory.
II RKIk"IIk._F_ITI_ i =_'F FA('RIUh_ =m
1 Turn TV on and tune to channel 3.
2 Plug VCR Power Cord into AC wall
outlet. VCR comes on and auto
channel and clock set starts.
• if screen below does not appear, check
VCR - TV connection and, if TV is
tuned to channel 3, try switching it to
channel 4.
• To change VCR's output channel,
please refer to "VCR's Output Channel"
in Advanced Operations book (p. 12).
IPlugging theAC PowerPlugintoanACoutletI
TV VCR IN FROM ANT Cable TV
Convor tet Box
• OUT TO TV
i WARNING
Over tightening "Nut type" RF coaxialcables
may damageiacks. Finger tightenonly.
3 Settings are made automatically.
When setup is done, this screen
appears.
1
If "AUTO CLOCK SET IS INCOMPLETE"
appears, manually set clock.
See below.
A_TO CLOCK SET _S
INCOMPLETE
PLEASE SET 0LO_K BY
m
_5
OH AUTO SET PROCEEDING-
If Auto Clock Set was incomplete.
I Press ACTION* on remote to display
CLOCK menu.
If you use a cabJe box, turn it on and set it
to the Pubtic Broadcasting Station (PBS)
channel in your time zone. If you use a
DSS receiver, it must be turned off.
:ACTION
2 Press • • to select the month and •
to set. in the same manner, select and
set the date, year, time, and DST
(Daylight Saving Time).
w
• Function buttons are inoperative during Initial
Setup.
• TO remove a cassette during Auto Set, press
EJECT on the remote or STOP twice on the
VCR. In this case, settings must be made
Loose or peeling labels
may cause tape jam.
VCR power comes on. "VCR" lights
on Multi Function Display.
If Auto VCR/TV (see p. 10 of
Advanced Operations book) is set to
"OFF;' press VCR/TV until "VCR"
lights on the Multi Function Display.
2 Press PLAY to p)ay tape.
,,If tape has no rec.tab (p.3), auto play begins.
Special Features During Plan/
• Forward/Reverse Scene Search
_,_ Press FF or REW.
_,_ Press PLAY to release.
After search has begun, each additional
press of FF or REW changes speed as
shown below.
[SLP] : Approx. 2fX _ * Approx. 9X
[LP] : Approx. 9X * * Approx. 7X
[SP] : Approx. 7X * _Approx. 3X
It at 21X, 9X, or 7X speed the picture is
interrupted, change speed to 9X, 7X, or 3X.
• PJeture interruption may occur with some TVs.
• FF and REW search speed may vary
depending on current tape position.
• Still (Freeze) Picture
-=-Press PAUSE/SLOW.
_,_ Press PLAY to release.
• Frame by Frame Picture
_ Press PAUSE/SLOW in Still mode.
_ Press PLAY to release.
• Slow Motion Picture
_,_ Hold down PAUSE/SLOW in Stillmode.
_'_ Press PLAY to release.
• These features work best in SP or SLP mode.
• The sound will be muted.
• To reduce picture noise, see "Manual
Tracking Control" on p. 3.
• After VCR is in Still or Slow mode 3 minL_es, it
auto switches to Stop mode to protect the tape
and the video heads.
• VCR power comes on. "VCR" lights
on Multi Function Display.
If Auto VCPJ'rV(see p. fg of
Advanced Operations book) is set to
"OFF;' press VCRfTV until "VCR"
lights on the Multi Function Display.
2 Press CH J,V or NUMBER keys
to select the channel.
• For "LINE" input, see p. 9 of "Advanced
Operations" book.
• If recording from a channel over 100, first
press 100 key then the other 2 digits.
3 Press SPEED
to select record speed (p, 3).
4 Press REC
to start recording.
• To edit, press PAUSE/SLOW to pause,
and again to resume recording.
5 Press STOP to stop recording.
iiiil
iiiii
iiiiil
iiiiii
iiiiii
((#
• OneTouch Recording
(recording in progress)
press REC repeatedlyto set lengthas follows:
30 rain._ 1hr. _- 1:30 _- 2:G0_ 3:00
"_"4:00 _" exit.
The VCR shuts off at thelength set.
• Record one station, watch another
PressVCR/TV
("VCR" goes out on Multi Function Display),
e,eotsh oe,son (reco, og¢ont,ouest
• PressSelectpAUSEvcRPrvChannelSm°de)on VCR (in STOP or
("VCR"lightsupon MultiFunctionDisplay),
"_ select channels on VCR.
O
• Watching one channel and recording
another is not possib,e when using Cab,e
Box or DSS Receiver.
• After 5 minutes in Pause mode, VCR stops
to protect the tape and the video heads.
3 Press STOP to stop tape.
• Press REW or FF in Stop mode to
Rewind or Fast Forward tape.
• Press EJECT on remote,
or STOP/EJECT on VCR to eject tape.
This video recorder, equipped with
HQ (High Quality) system, is
compatible with existing VHS
equipment. Only use tapes with the
mark. Only tapes tested and
inspected for use in 2, 4, 6, and 8
hour machines are recommended.
Auto Operation Functions
• Auto Play
Insert a tape ;'_ Power comes on "_ Play starts if there is no record tab (see p. 3)
• Auto Rewind
Play
Fast Forward ;'_ Tape end 4'- Rewind
• Play Auto Eject
(Repeat Play must be off)
P_ay_ Tape end -_ Rewired_ Tape e_ects itthere {s no record tab
