Panasonic PLCD42HD - Input Signal; Active Display

34 ……………………………………………………………………. INSTRUCTION MANUAL
42’’ WUXGA
42˝ Diagonal AM-TFT(Active-Matrix)
Pixel pitch(mm) :
0.4845mm(H) x 0.4845mm(V)
BRIGHTNESS: 500cd/㎡(Typical)
CONTRAST RATIO: 1300:1(Typical)
VIEWING ANGLE: 178°/178°(H/V)
LCD- Type
RESPONSE TIME: 5msec(G-to-G)
RESOLUTION (H x V)
1920X1080 @60Hz
FREQUENCY
HORIZONTAL: 31- 80KHz
VERTICAL: 56-75Hz
VIDEO(2ch input 1.0Vp-p, 75Ω terminated, loop-through out)
S-VIDEO(1ch input (Y/C), loop-through out)
COMPONENT(Y,Pb,Pr, Sound L/R)
DVI D(Digital Video Interface)
HDMI(High Definition Multimedia Interface)
PC RGB
AV(composite) Sound in/Out
PC Stereo Sound
INPUT SIGNAL
Audio Out
ACTIVE DISPLAY
AREA (H x V)
930mm X 523mm (36.61’’ X 20.59’’)
PACKING
DIMENSIONS
(W x H x D)
1300mm X 885mm X 390mm
(51.18’’ X 34.84” X 15.35”)
Net Weight : 31kg (68.34 lbs)
WEIGHT
Gross Weight : 39kg (85.98 lbs)
